MIL-PRF-55514/4F
*
TABLE I. Capacitor characteristics - Continued.
CHARACTERISTICS R and U - STYLE CFR05 CAPACITORS
Capacitance
Type designation
Rated voltage
Capacitance
Dimensions (in inches)
1/
(nom)
tolerance
(at 85°C)
D 3/
M 2/ Axial
L ±.050 (1.27)
available
µF
volts, dc
CFR05A-B156- -
15
100
F, G, J, K
.720 (18.29)
1.900 (48.20)
.032 (.81)
CFR05A-B186- -
18
100
F, G, J, K
.780 (19.81)
1.900 (48.20)
.032 (.81)
CFR05A-B206- -
20
100
F, G, J, K
.820 (20.83)
1.900 (48.20)
.032 (.81)
CFR05A-C103- -
.010
200
F, G, J, K
.176 (4.47)
.469 (11.91)
.025 (.64)
CFR05A-C123- -
.012
200
F, G, J, K
.187 (4.75)
.469 (11.91)
.025 (.64)
CFR05A-C153- -
.015
200
F, G, J, K
.203 (5.16)
.469 (11.91)
.025 (.64)
CFR05A-C183- -
.018
200
F, G, J, K
.217 (5.51)
.469 (11.91)
.025 (.64)
CFR05A-C223- -
.022
200
F, G, J, K
.235 (5.97)
.469 (11.91)
.025 (.64)
CFR05A-C273- -
.027
200
F, G, J, K
.255 (6.48)
.469 (11.91)
.025 (.64)
CFR05A-C333- -
.033
200
F, G, J, K
.277 (7.04)
.469 (11.91)
.025 (.64)
CFR05A-C393- -
.039
200
F, G, J, K
.298 (7.57)
.469 (11.91)
.025 (.64)
CFR05A-C473- -
.047
200
F, G, J, K
.313 (7.95)
.469 (11.91)
.025 (.64)
CFR05A-C563- -
.056
200
F, G, J, K
.244 (6.20)
.656 (16.66)
.025 (.64)
CFR05A-C683- -
.068
200
F, G, J, K
.264 (6.71)
.656 (16.66)
.025 (.64)
CFR05A-C823- -
.082
200
F, G, J, K
.285 (7.24)
.656 (16.66)
.025 (.64)
CFR05A-C104- -
.10
200
F, G, J, K
.310 (7.87)
.656 (16.66)
.025 (.64)
CFR05A-C124- -
.12
200
F, G, J, K
.366 (9.30)
.656 (16.66)
.032 (.81)
CFR05A-C154- -
.15
200
F, G, J, K
.304 (7.72)
.781 (19.84)
.025 (.64)
CFR05A-C184- -
.18
200
F, G, J, K
.329 (8.36)
.781 (19.84)
.032 (.81)
CFR05A-C224- -
.22
200
F, G, J, K
.359 (9.12)
.781 (19.84)
.032 (.81)
CFR05A-C274- -
.27
200
F, G, J, K
.393 (9.98)
.781 (19.84)
.032 (.81)
CFR05A-C334- -
.33
200
F, G, J, K
.431 (10.95)
.781 (19.84)
.032 (.81)
CFR05A-C394- -
.39
200
F, G, J, K
.363 (9.22)
1.031 (26.19)
.032 (.81)
CFR05A-C474- -
.47
200
F, G, J, K
.395 (10.03)
1.031 (26.19)
.032 (.81)
CFR05A-C564- -
.56
200
F, G, J, K
.427 (10.85)
1.031 (26.19)
.032 (.81)
CFR05A-C684- -
.68
200
F, G, J, K
.467 (11.86)
1.031 (26.19)
.032 (.81)
CFR05A-C824- -
.82
200
F, G, J, K
.509 (12.93)
1.031 (26.19)
.032 (.81)
CFR05A-C105- -
1
200
F, G, J, K
.574 (14.58)
1.031 (26.19)
.032 (.81)
CFR05A-C125- -
1.2
200
F, G, J, K
.624 (15.85)
1.031 (26.19)
.032 (.81)
CFR05A-C155- -
1.5
200
F, G, J, K
.520 (13.21)
1.531 (39.89)
.032 (.81)
CFR05A-C185- -
1.8
200
F, G, J, K
.579 (14.71)
1.531 (39.89)
.032 (.81)
CFR05A-C205- -
2
200
F, G, J, K
.607 (15.42)
1.531 (39.89)
.032 (.81)
CFR05A-C255- -
2.5
200
F, G, J, K
.670 (17.02)
1.531 (38.89)
.032 (.81)
CFR05A-C305- -
3
200
F, G, J, K
.727 (18.47)
1.531 (39.89)
.032 (.81)
CFR05A-C355- -
3.5
200
F, G, J, K
.779 (19.79)
1.531 (39.89)
.032 (.81)
CFR05A-C405- -
4
200
F, G, J, K
.828 (21.03)
1.531 (39.89)
.032 (.81)
CFR05A-C455- -
4.5
200
F, G, J, K
.796 (20.22)
1.781 (45.24)
.032 (.81)
CFR05A-C505- -
5
200
F, G, J, K
.835 (21.21)
1.781 (45.24)
.032 (.81)
CFR05A-C755- -
7.5
200
F, G, J, K
.870 (22.10)
2.281 (57.94)
.032 (.81)
CFR05A-C106- -
10
200
F, G, J, K
.995 (25.27)
2.281 (57.94)
.032 (.81)
CFR05A-E103- -
.01
400
F, G, J, K
.301 (7.65)
.469 (11.91)
.025 (.64)
CFR05A-E123- -
.012
400
F, G, J, K
.325 (3.26)
.469 (11.91)
.032 (.81)
CFR05A-E153- -
.015
400
F, G, J, K
.251 (6.38)
.656 (16.66)
.025 (.64)
CFR05A-E183- -
.018
400
F, G, J, K
.270 (6.86)
.656 (16.66)
.025 (.64)
CFR05A-E223- -
.022
400
F, G, J, K
.294 (7.47)
.656 (16.66)
.025 (.64)
CFR05A-E273- -
.027
400
F, G, J, K
.321 (8.15)
.656 (16.66)
.032 (.81)
CFR05A-E333- -
.033
400
F, G, J, K
.350 (8.89)
.656 (16.66)
.032 (.81)
CFR05A-E393- -
.039
400
F, G, J, K
.377 (9.58)
.656 (16.66)
.032 (.81)
CFR05A-E473- -
.047
400
F, G, J, K
.335 (8.51)
.781 (19.84)
.032 (.81)
CFR05A-E563- -
.056
400
F, G, J, K
.367 (9.32)
.781 (19.84)
.032 (.81)
CFR05A-E683- -
.068
400
F, G, J, K
.395 (10.03)
.781 (19.84)
.032 (.81)
CFR05A-E823- -
.082
400
F, G, J, K
.429 (10.90)
.781 (19.84)
.032 (.81)
CFR05A-E104- -
.1
400
F, G, J, K
.367 (9.32)
1.031 (26.19)
.032 (.81)
CFR05A-E124- -
.12
400
F, G, J, K
.399 (10.13)
1.031 (26.19)
.032 (.81)
CFR05A-E154- -
.15
400
F, G, J, K
.441 (11.20)
1.031 (26.19)
.032 (.81)
See footnotes at end of table.
