MIL-PRF-55514/4F
*
TABLE I. Capacitor characteristics.
CHARACTERISTICS R and U - STYLE CFR05 CAPACITORS
Capacitance
Type designation
Rated voltage
Capacitance
Dimensions (in inches)
1/
(nom)
tolerance
(at 85°C)
D 3/
M 2/ Axial
L ±.050 (1.27)
available
µF
volts, dc
CFR05A-A102- -
.0010
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A122- -
.0012
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A152- -
.0015
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A182- -
.0018
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A222- -
.0022
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A272- -
.0027
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A332- -
.0033
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A392- -
.0039
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A472- -
.0047
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A562- -
.0056
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A682- -
.0068
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A822- -
.0082
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A103- -
.010
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A123- -
.012
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A153- -
.015
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A183- -
.018
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A223- -
.022
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A273- -
.027
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A333- -
.033
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A393- -
.039
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A473- -
.047
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A563- -
.056
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A683- -
.068
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A823- -
.082
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A104- -
.1
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A124- -
.12
50
F, G, J, K
.150 (3.81)
.400 (10.16)
.020 (.51)
CFR05A-A154- -
.15
50
F, G, J, K
.160 (4.06)
.400 (10.16)
.020 (.51)
CFR05A-A184- -
.18
50
F, G, J, K
.150 (3.81)
.530 (13.46)
.020 (.51)
CFR05A-A224- -
.22
50
F, G, J, K
.150 (3.81)
.530 (13.46)
.020 (.51)
CFR05A-A274- -
.27
50
F, G, J, K
.160 (4.06)
.530 (13.46)
.020 (.51)
CFR05A-A334- -
.33
50
F, G, J, K
.180 (4.57)
.530 (13.46)
.020 (.51)
CFR05A-A394- -
.39
50
F, G, J, K
.190 (4.83)
.530 (13.46)
.020 (.51)
CFR05A-A474- -
.47
50
F, G, J, K
.200 (5.08)
.530 (13.46)
.020 (.51)
CFR05A-A564- -
.56
50
F, G, J, K
.220 (5.59)
.530 (13.46)
.020 (.51)
CFR05A-A684- -
.68
50
F, G, J, K
.240 (6.10)
.530 (13.46)
.020 (.51)
CFR05A-A824- -
.82
50
F, G, J, K
.260 (6.60)
.530 (13.46)
.020 (.51)
CFR05A-A105- -
1
50
F, G, J, K
.280 (7.11)
.530 (13.46)
.020 (.51)
CFR05A-A125- -
1.2
50
F, G, J, K
.260 (6.60)
.680 (17.27)
.020 (.51)
CFR05A-A155- -
1.5
50
F, G, J, K
.280 (7.11)
.680 (17.27)
.020 (.51)
CFR05A-A185- -
1.8
50
F, G, J, K
.290 (7.37)
.780 (19.81)
.020 (.51)
CFR05A-A205- -
2
50
F, G, J, K
.300 (7.62)
.780 (19.81)
.020 (.51)
CFR05A-A255- -
2.5
50
F, G, J, K
.340 (8.64)
.780 (19.81)
.020 (.51)
CFR05A-A305- -
3
50
F, G, J, K
.370 (9.40)
.780 (19.81)
.025 (.64)
CFR05A-A355- -
3.5
50
F, G, J, K
.400 (10.16)
.780 (19.81)
.025 (.64)
CFR05A-A405- -
4
50
F, G, J, K
.370 (9.40)
.950 (24.13)
.025 (.64)
CFR05A-A455- -
4.5
50
F, G, J, K
.390 (9.91)
.950 (24.13)
.025 (.64)
CFR05A-A505- -
5
50
F, G, J, K
.360 (9.14)
1.170 (28.73)
.025 (.64)
CFR05A-A605- -
6
50
F, G, J, K
.390 (9.91)
1.170 (28.73)
.025 (.64)
CFR05A-A805- -
8
50
F, G, J, K
.450 (11.43)
1.170 (28.73)
.025 (.64)
CFR05A-A106- -
10
50
F, G, J, K
.500 (12.70)
1.170 (28.73)
.032 (.81)
CFR05A-A126- -
12
50
F, G, J, K
.540 (13.72)
1.170 (28.73)
.032 (.81)
CFR05A-A156- -
15
50
F, G, J, K
.600 (15.24)
1.170 (28.73)
.032 (.81)
CFR05A-A186- -
18
50
F, G, J, K
.580 (14.73)
1.450 (36.33)
.032 (.81)
CFR05A-A206- -
20
50
F, G, J, K
.610 (15.49)
1.450 (36.33)
.032 (.81)
CFR05A-A256- -
25
50
F, G, J, K
.580 (14.73)
1.900 (48.20)
.032 (.81)
