MIL-PRF-55365/8J
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Termination finish: In accordance with MIL-PRF-55365.
Operating temperature range: -55°C to +125°C.
Product level designator: In accordance with MIL-PRF-55365.
DC leakage (DCL): See table I.
Capacitance: See table I.
Capacitance tolerance: ±5 percent (J), ±10 percent (K), or ±20 percent (M).
Dissipation factor (DF): See table I.
Resistance to soldering heat: In accordance with MIL-PRF-55365.
Stability at low and high temperatures: In accordance with MIL-PRF-55365.
Life:
2,000 hours: In accordance with MIL-PRF-55365.
10,000 hours: In accordance with MIL-PRF-55365.
Solderability: In accordance with MIL-PRF-55365, except that following steam aging; test samples may have a
30 minute bake out at +150°C prior to solder dipping.
Marking: In accordance with MIL-PRF-55365, to be marked on top of case as follows: Print orientation is
optional.
Case code A
Case codes B, C, and D
J
(+) polarity stripe, J = JAN
J
(+) polarity stripe, J = JAN
105X
- capacitance in picofarad code
105
- capacitance in picofarad code
manufacturer's identifier
35X
- rated voltage; manufacturer's
identifier
Alternate case code A marking
X
(+) polarity stripe, X = manufacturer's identifier
105J
- capacitance in picofarad code; J = JAN
At the option of the manufacturer, the lot date code may be marked on the top of the case for any case code.
