MIL-PRF-55365/7B
TABLE I. Style CWR10 characteristics - Continued.
DC Leakage
Dissipation factor
Max ESR
Pin
DC rated
Cap.
100 kHz Case
(max)
(max)
+25°C size
+85°C
1/
voltage
(nom)
-55°C
(+85°C)
+25°C
+85°C
+125°C
+25°C +125°C
µF
µA
µA
µA
Volts
%
%
%
Ohms
CWR10D-476---
6
47.0
3.0
30.0
36.0
6
9
12
0.600
Y
CWR10D-107---
6
100.0
6.0
60.0
72.0
6
9
12
0.400
Z
CWR10D-187---
6
180.0
13.5
135.0
162.0
10
12
15
0.080
R
CWR10D-227---
6
220.0
13.5
135.0
162.0
10
12
15
0.080
R
CWR10F-155---
10
1.5
0.5
5.0
6.0
6
8
8
10.000
C
CWR10F-335---
10
3.3
1.0
10.0
12.0
6
8
8
2.500
S
CWR10F-475---
10
4.7
1.0
10.0
12.0
6
8
8
2.000
S
CWR10F-685---
10
6.8
1.0
10.0
12.0
6
8
8
2.000
V
CWR10F-106---
10
10.0
1.5
15.0
18.0
6
8
8
1.500
X
CWR10F-156---
10
15.0
3.0
30.0
36.0
6
8
8
1.000
X
CWR10F-226---
10
22.0
3.0
30.0
36.0
6
8
8
0.600
Y
CWR10F-336---
10
33.0
3.0
30.0
36.0
6
8
8
0.400
Z
CWR10F-476---
10
47.0
5.0
50.0
60.0
6
8
8
0.400
Z
CWR10F-107---
10
100.0
10.0
100.0
120.0
10
12
15
0.075
R
CWR10F-127---
10
120.0
12.0
120.0
144.0
10
12
15
0.070
R
CWR10F-127---
10
150.0
15.0
150.0
180.0
10
12
15
0.065
R
CWR10H-105---
15
1.0
0.5
5.0
6.0
6
8
8
10.000
C
CWR10H-225---
15
2.2
1.0
10.0
12.0
6
8
8
3.500
S
CWR10H-335---
15
3.3
1.0
10.0
12.0
6
8
8
2.500
S
CWR10H-475---
15
4.7
1.0
10.0
12.0
6
8
8
2.000
V
CWR10H-685---
15
6.8
1.5
15.0
18.0
6
8
8
1.500
X
CWR10H-106---
15
10.0
1.5
15.0
18.0
6
8
8
1.500
X
CWR10JH156---
15
15.0
2.0
20.0
24.0
6
8
8
0.600
Y
CWR10H-226---
15
22.0
3.0
30.0
36.3
6
8
8
0.400
Z
CWR10H-336---
15
33.0
5.0
50.0
60.0
6
8
8
0.400
Z
CWR10H-686---
15
68.0
10.5
105.0
126.0
6
8
10
0.095
R
CWR10J-684---
20
.68
0.5
5.0
6.0
6
8
8
12.000
C
CWR10J-155---
20
1.5
1.0
10.0
12.0
6
8
8
3.500
S
CWR10J-225---
20
2.2
1.0
10.0
12.0
4
6
8
3.500
S
CWR10J-335---
20
3.3
1.5
15.0
18.0
4
6
8
3.000
V
CWR10J-475---
20
4.7
1.5
15.0
18.0
4
6
8
1.500
X
CWR10J-685---
20
6.8
2.0
20.0
24.0
6
8
8
1.500
X
CWR10J-106---
20
10.0
3.0
30.0
36.0
6
8
8
1.000
Y
CWR10J-156---
20
15.0
3.0
30.0
36.0
6
8
8
0.600
Z
CWR10J-226---
20
22.0
4.5
45.0
54.0
6
8
8
0.400
Z
CWR10J-476---
20
47.0
9.5
95.0
114.0
6
8
8
0.110
R
CWR10K-474---
25
.47
0.5
5.0
6.0
4
6
8
15.000
C
CWR10K-684---
25
.68
0.5
5.0
6.0
4
6
8
5.000
S
CWR10K-105---
25
1.0
1.0
10.0
12.0
4
6
8
3.500
S
CWR10K-155---
25
1.5
1.0
10.0
12.0
6
8
8
3.500
S
CWR10K-225---
25
2.2
1.0
10.0
12.0
4
6
8
2.000
V
CWR10K-335---
25
3.3
1.0
10.0
12.0
6
8
8
1.500
X
CWR10K-475---
25
4.7
12.0
120.0
144.0
6
8
8
1.500
X
CWR10K-685---
25
6.8
3.0
30.0
36.0
6
8
8
1.000
Y
