MIL-PRF-49464/1C
TABLE III. Temperature coefficient W capacitor characteristics. Continued.
Case sizes
Cap.
Volt. Temp.
Part or Identifying
B C D E F G H J K Tolerance
Number (PIN) 1/
(pF)
(dc) coeff.
12 15 17 20 22 25 27 30 35
M49464W01121-D--H-
120
100
W
H
J
K
K,M
M49464W01151-D--H-
150
100
W
J
K
K,M
M49464W01181-D--H-
180
100
W
J
K
K,M
M49464W01201-D--H-
200
100
W
J
K
K,M
M49464W01221-DK-H-
220
100
W
K
K,M
M49464W01241-DK-H-
240
100
W
K
K,M
M49464W01271-DK-H-
270
100
W
K
K,M
M49464W01301-DK-H-
300
100
W
K
K,M
1/ Complete PIN shall include additional symbols to indicate capacitance tolerance, case code
(where several case codes are available), termination configuration code (A, B, or C), and
failure rate level (M, P, R, or S).
