INCH-POUND
MIL-PRF-49464/1C
24 June 2009
SUPERSEDING
MIL-PRF-49464/1B
3 June 2004
PERFORMANCE SPECIFICATION SHEET
CAPACITORS, CHIP, SINGLE LAYER, FIXED UNENCAPSULATED,
CERAMIC DIELECTRIC, ESTABLISHED RELIABILITY,
STYLE CPCR01 (HIGH FREQUENCY)
This specification sheet is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-49464.
Termination
configuration
Dimensions (inches)
Case
Inches
mm
Inches
mm
W
T
Nominal P
Minimum B
code
.0005
0.01
.018
0.46
.001
0.03
.020
0.51
B
.012 ± .002
.005 ± .002
.009
.0005
.002
0.05
.021
0.53
C
.015 ± .002
.005 ± .002
.011
.001
.005
0.13
.022
0.56
D
.017 ± .002
.005 ± .002
.013
.001
.009
0.23
.023
0.58
.011
0.28
.025
0.64
E
.020 ± .002
.005 ± .002
.016
.001
.012
0.30
.026
0.66
F
.022 ± .002
.005 ± .002
.018
.001
.013
0.33
.027
0.69
G
.025 ± .002
.005 ± .002
.021
.001
.015
0.38
.030
0.76
H
.027 ± .002
.005 ± .002
.023
.001
.016
0.41
.031
0.79
J
.030 ± .002
.005 ± .002
.026
.001
.017
0.43
.035
0.89
K
.035 ± .005
.005 ± .002
.031
.001
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Alternate configurations are allowable if they fall within the envelope given and
the performance characteristics are not affected.
FIGURE 1. CPCR01 capacitors.
AMSC N/A
FSC 5910
