MIL-PRF-39022/7D
TABLE IV. Substitutability data - Continued.
Type designation in
Dash number in
MIL-C-39022/7A thru MIL-PRF-39022/7D 1/
MIL-C-39022/7
2/
L(5.0)
M(1.0)
P(0.1)
R(0.01)
S(0.001)
1008
1037
1067
1097
1127
CHR49A1QW105K-
1009
1038
1068
1098
1128
CHR49A1QU155K-
1039
1069
1099
1129
CHR49A1QV225K-
1352
1010
1372
1392
1412
1040
1070
1110
1130
CHR49A1QT335K-
1011
1353
1373
1393
1413
1012
1041
1071
1101
1131
CHR49A1QS475K-
1042
1072
1102
1132
CHR49A1QR585K-
1354
1374
1394
1414
1013
1355
1375
1395
1415
1043
1073
1103
1133
CHR49A1QP106K-
1/ FRL L for revision C only.
2/ Complete type designation will include additional symbols for capacitance
tolerance and failure rate level.
Qualification:
Accelerated conditions: 140 percent of rated ac voltage (400 Hz) for 2,000 +72, -0 hours on voltages of ≤ 300
volts; 120 percent of rated ac voltage (400 Hz) for 2,000 +72, -0 hours on voltages of ≥ 350 volts.
Rated conditions: 100 percent of rated voltage for 10,000 +96, -0 hours.
DF (at +85°C +4°C, -0°C) between 24 and 48 hours of test: Not greater than initial limit.
During last 48 hours of test: Not greater than 0.75 percent.
IR:
Terminal to terminal: Not less than 1,000 megohm/microfarads. Need not exceed 5,000 megohms.
Terminals to case: 5,000 megohms, minimum.
Capacitance: Within ± 10 percent of initial value.
DF (at +25°C ± 3°C after life): Not greater than 0.75 percent.
Quality conformance: 240 hours at accelerated conditions and meet the requirements for qualification test.
Extended life:
Accelerated conditions: 1,760 +72, -0 hours.
Marking: In accordance with MIL-PRF-39022.
Part or Identifying Number (PIN): M39022/07- (dash number from table I).
Changes from previous issue. Marginal notations are not used in this revision to identify changes with respect to
the previous issue due to the extensiveness of the changes.
