MIL-PRF-39022/2G
TABLE II. Insulation resistance.
At dc voltage of
200 V
400 V
In megohms:
At +25°C ± 3°C (need not exceed)
12,000
12,000
At +125°C +4°C, -0°C (need not exceed)
150
600
In megohms x microfarads (minimum):
At +25°C ± 3°C
2,000
2,000
At +125°C +4°C, -0°C
10
40
TABLE III. Metric equivalents of decimal inches. 1/
Inches
mm
Inches
mm
Inches
mm
.031
0.79
1.000
25.40
1.812
46.02
.062
1.57
1.062
26.97
1.844
46.84
.312
7.92
1.125
28.58
1.875
47.63
.400
10.16
1.312
33.32
2.062
52.37
.500
12.70
1.375
34.93
2.125
53.98
.562
14.27
1.562
39.67
2.562
65.07
.672
17.07
1.625
41.28
2.625
66.68
.750
19.05
1.781
45.24
1/ Metric equivalents are given for general information only.
Salt atmosphere (corrosion): Method 101 of MIL-STD-202, condition B (48 hours).
Salt solution: 5 percent.
Moisture resistance: Method 106 of MIL-STD-202.
Immersion: Method 104 of MIL-STD-202, condition C.
DWV:
Insulating sleeves: Greater than 4,000 volts, dc.
Terminal to terminal: 200 percent of rated voltage.
Terminals to case (when case is not a terminal): 200 percent of rated voltage.
IR:
Insulating sleeves: 100 megohms, minimum.
Terminal to terminal: Not less than 50 percent of value specified in table II.
Terminals to case (when case is not a terminal): 5,000 megohms, minimum.
Capacitance: Within ± 10 percent of initial value.
DF: Not more than 1.1 percent.
5
