MIL-PRF-39022-11 Capacitors, Fixed, Metallized Plastic Dielectric, Direct-Current, Hermetically Sealed, Styles Chr20, Chr21, Chr22, Chr23, Chr24, Chr25 \(See Notice 1 For Replacement Information\)

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7


. . .
MIL-PRF-39022/11D
TABLE I. Capacitor characteristics and dimensions. ­ Continued.
Part or Identifying
DC rated Capacitance
Capacitance
Number (PIN) 1/
voltage
Value in µF
tolerance
LS
CHR22
M39022/11C104--
100
.10
F, G, J, K
.190 (4.83)
.380 (9.65)
.450 (11.43)
.400 (10.16)
M39022/11C124--
100
.12
F, G, J, K
.190 (4.83)
.380 (9.65)
.450 (11.43)
.400 (10.16)
M39022/11C154--
100
.15
F, G, J, K
.220 (5.59)
.500 (12.70)
.450 (11.43)
.400 (10.16)
M39022/11C184--
100
.18
F, G, J, K
.220 (5.59)
.500 (12.70)
.450 (11.43)
.400 (10.16)
M39022/11C224--
100
.22
F, G, J, K
.220 (5.59)
.500 (12.70)
.450 (11.43)
.400 (10.16)
CHR23
M39022/11D332--
150
.0033
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11D392--
150
.0039
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11D472--
150
.0047
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11D562--
150
.0056
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11D682--
150
.0068
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11D223--
150
.022
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11D273--
150
.027
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11D333--
150
.033
F, G, J, K
.190 (4.83)
.380 (9.65)
.340 (8.64)
.300 (7.62)
M39022/11D393--
150
.039
F, G, J, K
.190 (4.83)
.380 (9.65)
.340 (8.64)
.300 (7.62)
M39022/11D563--
150
.056
F, G, J, K
.190 (4.83)
.380 (9.65)
.450 (11.43)
.400 (10.16)
M39022/11D683--
150
.068
F, G, J, K
.190 (4.83)
.380 (9.65)
.450 (11.43)
.400 (10.16)
M39022/11D823--
150
.082
F, G, J, K
.220 (5.59)
.500 (12.70)
.450 (11.43)
.400 (10.16)
M39022/11D104--
150
.10
F, G, J, K
.220 (5.59)
.500 (12.70)
.450 (11.43)
.400 (10.16)
CHR24
M39022/11E222--
200
.0022
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11E272--
200
.0027
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11E332--
200
.0033
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11E392--
200
.0039
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11E472--
200
.0047
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11E123--
200
.012
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11E153--
200
.015
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11E183--
200
.018
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11E223--
200
.022
F, G, J, K
.190 (4.83)
.380 (9.65)
.340 (8.64)
.300 (7.62)
M39022/11E273--
200
.027
F, G, J, K
.190 (4.83)
.380 (9.65)
.340 (8.64)
.300 (7.62)
M39022/11E333--
200
.033
F, G, J, K
.190 (4.83)
.380 (9.65)
.450 (11.43)
.400 (10.16)
M39022/11E393--
200
.039
F, G, J, K
.190 (4.83)
.380 (9.65)
.450 (11.43)
.400 (10.16)
M39022/11E473--
200
.047
F, G, J, K
.190 (4.83)
.380 (9.65)
.450 (11.43)
.400 (10.16)
M39022/11E563--
200
.056
F, G, J, K
.220 (5.59)
.500 (12.70)
.450 (11.43)
.400 (10.16)
M39022/11E683--
200
.068
F, G, J, K
.220 (5.59)
.500 (12.70)
.450 (11.43)
.400 (10.16)
CHR25
M39022/11F102--
300
.001
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11F122--
300
.0012
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11F152--
300
.0015
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11F182--
300
.0018
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11F222--
300
.0022
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11F272--
300
.0027
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11F332--
300
.0033
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11F392--
300
.0039
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11F472--
300
.0047
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11F562--
300
.0056
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11F682--
300
.0068
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11F822--
300
.0082
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11F103--
300
.01
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11F123--
300
.012
F, G, J, K
.190 (4.83)
.380 (9.65)
.340 (8.64)
.300 (7.62)
M39022/11F153--
300
.015
F, G, J, K
.190 (4.83)
.380 (9.65)
.340 (8.64)
.300 (7.62)
M39022/11F183--
300
.018
F, G, J, K
.190 (4.83)
.380 (9.65)
.450 (11.43)
.400 (10.16)
