MIL-PRF-39022-11 Capacitors, Fixed, Metallized Plastic Dielectric, Direct-Current, Hermetically Sealed, Styles Chr20, Chr21, Chr22, Chr23, Chr24, Chr25 \(See Notice 1 For Replacement Information\)

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7


. . .
MIL-PRF-39022/11D
TABLE I. Capacitor characteristics and dimensions.
Part or Identifying
DC rated Capacitance
Capacitance
Number (PIN) 1/
voltage
Value in µF
tolerance
LS
CHR20
M39022/11A333--
30
.033
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11A393--
30
.039
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11A473--
30
.047
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11A563--
30
.056
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11A683--
30
.068
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11A823--
30
.082
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11A184--
30
.18
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11A224--
30
.22
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11A274--
30
.27
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11A334--
30
.33
F, G, J, K
.190 (4.83)
.380 (9.65)
.340 (8.64)
.300 (7.62)
M39022/11A394--
30
.39
F, G, J, K
.190 (4.83)
.380 (9.65)
.340 (8.64)
.300 (7.62)
M39022/11A474--
30
.47
F, G, J, K
.190 (4.83)
.380 (9.65)
.450 (11.43)
.400 (10.16)
M39022/11A564--
30
.56
F, G, J, K
.190 (4.83)
.380 (9.65)
.450 (11.43)
.400 (10.16)
M39022/11A684--
30
.68
F, G, J, K
.190 (4.83)
.380 (9.65)
.450 (11.43)
.400 (10.16)
M39022/11A824--
30
.82
F, G, J, K
.220 (5.59)
.500 (12.70)
.450 (11.43)
.400 (10.16)
M39022/11A105--
30
1.0
F, G, J, K
.220 (5.59)
.500 (12.70)
.450 (11.43)
.400 (10.16)
CHR21
M39022/11B103--
50
.01
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11B123--
50
.012
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11B153--
50
.015
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11B183--
50
.018
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11B223--
50
.022
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11B273--
50
.027
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11B333--
50
.033
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11B393--
50
.039
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11B473--
50
.047
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11B683--
50
.068
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11B823--
50
.082
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11B104--
50
.10
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11B124--
50
.12
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11B154--
50
.15
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11B184--
50
.18
F, G, J, K
.190 (4.83)
.380 (9.65)
.340 (8.64)
.300 (7.62)
M39022/11B224--
50
.22
F, G, J, K
.190 (4.83)
.380 (9.65)
.340 (8.64)
.300 (7.62)
M39022/11B274--
50
.27
F, G, J, K
.190 (4.83)
.380 (9.65)
.340 (8.64)
.300 (7.62)
M39022/11B334--
50
.33
F, G, J, K
.190 (4.83)
.380 (9.65)
.450 (11.43)
.400 (10.16)
M39022/11B394--
50
.39
F, G, J, K
.190 (4.83)
.380 (9.65)
.450 (11.43)
.400 (10.16)
M39022/11B474--
50
.47
F, G, J, K
.220 (5.59)
.500 (12.70)
.450 (11.43)
.400 (10.16)
M39022/11B564--
50
.56
F, G, J, K
.220 (5.59)
.500 (12.70)
.450 (11.43)
.400 (10.16)
M39022/11B684--
50
.68
F, G, J, K
.220 (5.59)
.500 (12.70)
.450 (11.43)
.400 (10.16)
CHR22
M39022/11C562--
100
.0056
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11C682--
100
.0068
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11C822--
100
.0082
F, G, J, K
.110 (2.79)
.210 (5.33)
.240 (6.10)
.200 (5.08)
M39022/11C103--
100
.01
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11C123--
100
.012
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11C153--
100
.015
F, G, J, K
.170 (4.32)
.270 (6.86)
.240 (6.10)
.200 (5.08)
M39022/11C333--
100
.033
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11C393--
100
.039
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11C473--
100
.047
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11C563--
100
.056
F, G, J, K
.170 (4.32)
.270 (6.86)
.340 (8.64)
.300 (7.62)
M39022/11C683--
100
.068
F, G, J, K
.190 (4.83)
.380 (9.65)
.340 (8.64)
.300 (7.62)
M39022/11C823--
100
.082
F, G, J, K
.190 (4.83)
.380 (9.65)
.340 (8.64)
.300 (7.62)
3
