MIL-PRF-39018/7C
TABLE I. Style CUR19 capacitors Continued.
DC rated
Capaci-
DC
ESR
Imped-
DC leakage
RMS
Case
Dash number 2/
(max)
voltage
tance
surge
(max)
ance
ripple
size
@ 105°C
25°C
85°C
current 1/
voltage
120Hz,
(max)
Low
High
10°C rise
25°C
25°C
& 105°C
frequency
frequency
10 kHz-
vibration
vibration
10 kHz
1MHz
1MHz
µF
Volts
Volts
Ohms
Ohms
mA
Amps
150
200
200
0.650
0.273
87
520
1.40
K2
0118-
0318-
150
300
200
0.430
0.181
106
640
1.80
J4
0119-
0319-
150
380
200
0.340
0.143
120
720
2.35
K4
0120-
0320-
150
470
200
0.280
0.096
133
800
2.85
K5
0121-
0321-
200
50
250
2.600
0.780
50
300
0.60
H1
0122-
0322-
200
85
250
1.530
0.460
65
390
0.75
J1
0123-
0323-
200
100
250
1.300
0.390
71
430
0.95
J2
0124-
0324-
200
150
250
0.865
0.259
87
520
1.25
J3
0125-
0325-
200
200
250
0.650
0.195
100
600
1.67
K3
0126-
0326-
200
250
250
0.520
0.156
112
670
1.90
J5
0127-
0327-
200
320
250
0.405
0.122
126
760
2.50
K5
0128-
0328-
1/ The ripple current values shown are representative values not supported by test data.
2/ The last letter in the dash number will indicate the applicable FR level symbol ("M","P", "R", or "S").
