MIL-PRF-39018/7C
INSULATED DIMENSIONS
Typical
Case
weight
INCHES
size
(GRAMS)
L
Max. Dia
Min
Max
H1
1.625
1.843
.785
20.3
H2
2.125
2.343
.785
26.8
H3
2.625
2.843
.785
33.2
H4
3.125
3.343
.785
39.7
H5
3.625
3.843
.785
45.9
J1
1.625
1.843
.910
26.9
J2
2.125
2.343
.910
36.2
J3
2.625
2.843
.910
45.4
J4
3.125
3.343
.910
55.0
J5
3.625
3.843
.910
64.0
K1
1.625
1.843
1.035
34.3
K2
2.125
2.343
1.035
45.9
K3
2.625
2.843
1.035
57.2
K4
3.125
3.343
1.035
68.5
K5
3.625
3.843
1.035
81.9
Inches
mm
.002
.05
.008
.20
.015
.38
.040
1.02
.625
15.88
.785
19.94
.910
23.11
1.035
26.29
1.625
41.28
1.843
46.81
2.125
53.98
2.343
59.51
2.625
66.68
2.843
72.21
3.125
79.38
3.343
84.91
3.625
92.08
3.843
97.61
FIGURE 1. Styles CUR19 capacitors - Continued.
