INCH-POUND
MIL-PRF-39018/1H
20 February 2009
SUPERSEDING
MIL-PRF-39018/1G
2 March 2007
PERFORMANCE SPECIFICATION SHEET
CAPACITORS, FIXED, ELECTROLYTIC (ALUMINUM OXIDE)
(POLARIZED), NON-ESTABLISHED RELIABILITY AND ESTABLISHED RELIABILITY
STYLES CU12 (UNINSULATED), CU13 (INSULATED), AND CUR13 (INSULATED)
STYLE CU12 INACTIVE FOR
DESIGN AFTER 23 MARCH 1972
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the capacitors described herein shall consist
of this specification sheet and MIL-PRF-39018.
Dimensions
D ± .015
Case
L ± .031
size
Inches
mm
Inches
mm
See note 4
9.53
.375
0.05
.002
23.83
.938
0.20
.008
.281
.938
A0
28.57
1.125
0.38
.015
.375
.938
A1
34.92
1.375
0.79
.031
.375
1.125
A2
38.1
1.50
0.81
.032
.375
1.375
A3
41.27
1.625
3.56
.140
.375
1.625
A4
55.58
2.188
6.35
.250
.375
2.188
A5
68.28
2.688
7.14
.281
.375
2.688
A6
FIGURE 1. Styles CU12, CU13, and CUR13 capacitors.
