MIL-PRF-39014/23B
4,000 hours through 32,000 hours:
At 25°C, not less than 15 percent of initial 25°C requirement.
IR -
At 125°C, not less than 15 percent of initial 125°C requirement.
-
ĆC -
±20 percent from initial measured value.
Dissipation factor - Not greater than 2.5 percent
Accelerated conditions, 200 percent of dc rated voltage at 125°C.
0 hour and 250 hours:
At 25°C, not less than 50 percent of initial 25°C requirement.
IR -
At 125°C, not less than 50 percent of initial 125°C requirement.
-
ĆC -
±20 percent from initial measured value.
Dissipation factor - Not greater than 2.5 percent
1,000 hours, 2,000 hours, and 4,000 hours:
At 25°C, not less than 15 percent of initial 25°C requirement.
IR -
At 125°C, not less than 15 percent of initial 125°C requirement.
-
ĆC -
±20 percent from initial measured value.
Dissipation factor - Not greater than 2.5 percent.
Marking: In accordance with MIL-PRF-39014 except the minimum marking as show in the following example will be
permitted. Full marking shall be included in the package.
Front
Reverse side
JAN, and two digit manufacturer's code or symbol 1/
M390
J--
Specification sheet No.
14/23
7736
Date code in accordance with MIL-PRF-39014.
Four digit dash number
0001
A
Lot Code
Part or Identifying Number (PIN): M39014/23-(dash number from table I).
1/ Location of manufacturer's code or symbol is optional.
3
