MIL-PRF-39014/20E
TABLE I. Electrical characteristics and dash number.
Dash number 1/
Dimension, inches 2/
DC rated
Capacitance, Capacitance
Failure rate level (%/1,000 hours)
voltage,
tolerance,
pF
± percent
volts
M (1.0) P (0.1)
R (0.01) S (0.001)
±.010 (.25)
0004
0007
0010
0013
1,200,000
10
50
.130 (3.30)
±.010 (.25)
0005
0008
0011
0014
1,500,000
10
50
.130 (3.30)
±.010 (.25)
0006
0009
0012
0015
2,000,000
10
50
.130 (3.30)
±.015 (.38)
0104
0107
0110
0113
1,200,000
10
50
.145 (3.68)
±.015 (.38)
0105
0108
0111
0114
1,500,000
10
50
.145 (3.68)
±.015 (.38)
0106
0109
0112
0115
2,000,000
10
50
.145 (3.68)
1/ Complete PIN is in the format M39014/20-NNNN, where NNNN is the 4 digit dash number from the table.
*
2/ Metric equivalents are given in parentheses.
*
TABLE II. Substitutability data.
Substitutable for dash numbers in:
Dash numbers in
MIL-PRF-39014/20E 1/
MIL-C-39014/20A(EC)
M
P
R
S
L
M
P
R
S
0004
0007
0010
0013
0001
0004
0007
0010
0013
0005
0008
0011
0014
0002
0005
0008
0011
0014
0006
0009
0012
0015
0003
0006
0009
0012
0015
0104
0107
0110
0113
0101
0104
0107
0110
0113
0105
0108
0111
0114
0102
0105
0108
0111
0114
0106
0109
0112
0115
0103
0106
0109
0112
0115
1/ Dash numbers in lower FR level columns are substitutable for dash
numbers in all higher FR level columns.
Changes from previous issue: The margins of this specification are marked with asterisks to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government assumes
no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
