MIL-PRF-39014/20E
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case: Molded or preformed.
Capacitance value: See table I.
Capacitance tolerance: See table I.
Operating temperature range: -55°C to +125°C.
Voltage rating: See table I.
Dissipation factor: Not more than 2.5 percent.
Dielectric withstanding voltage:
Body insulation: Shall be able to withstand 1,300 volts between leads and case.
*
Insulation resistance:
At 25°C: Not less than 100,000 megohms or 1,000 megohm-microfarads, whichever is less.
At 125°C: Not less than 10,000 megohms or 100 megohm-microfarads, whichever is less.
Insertion loss: Not applicable.
Seal: Not applicable.
Voltage-temperature limits: In accordance with MIL-PRF-39014.
Capacitance change with reference to 25°C
Steps A through D of table V
Steps E through G of table V
Bias = 0 volts
Bias = rated voltage
±15 percent
+15, -25 percent
Immersion:
IR: Not less than 50 percent of initial 25°C requirements.
Salt spray (corrosion): In accordance with MIL-PRF-39014.
Resistance to soldering heat:
ĆC: +15, -5 percent of the initial 25°C measurement.
