MIL-PRF-39003/1K
Dimensions
Case
size
L ±.031 (0.79)
+.016 (0.41)
M±.002 (0.05)
J Max
D -.015 (0.38)
A
.286 ( 7.26)
.135 (3.43)
.020 (0.51)
.422 (10.72)
B
.474 (12.04)
.185 (4.70)
.020 (0.51)
.610 (15.49)
C
.686 (17.42)
.289 (7.34)
.025 (0.64)
.822 (20.88)
D
.786 (19.96)
.351 (8.92)
.025 (0.64)
.922 (23.42)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. The case insulation shall extend .015 (0.38 mm) minimum beyond each end. However, when a shrink-fitted
insulation is used, it shall lap over the ends of the capacitor body.
4. Lead length may be a minimum of 1-inch long for use in tape and reel automatic insertion equipment, when
specified.
FIGURE 1. Dimensions and configuration - Continued.
REQUIREMENTS:
Design and construction:
Dimensions and configuration: See figure 1.
Case type: Tubular, insulated.
Material: Metal (alloy unspecified).
Type of seal: Hermetic.
Leads: Type N-32, N-52, W-32, or W-52 of MIL-STD-1276.
Operating temperature: -55°C to +125°C.
Failure rate level: See table I.
DC leakage (DCL): See table I.
Capacitance (Cap.) (nom): See table I.
Cap. tolerance: ±5, ±10, or ±20 percent as shown in table I.
Dissipation factor (DF): See table I.
Stability at low and high temperatures: In accordance with MIL-PRF-39003.
2
