MIL-PRF-39001/6A
TABLE I. Type designations - Continued.
STYLE CMR16
Type designation1/
Capacitance value
DC rated voltage
Capacitance tolerance available
(pF)
(volts)
CMR16E510-0D-
51
500
F, G, J
CMR16E560-0D-
56
500
F, G, J
CMR16E620-0D-
62
500
F, G, J
CMR16E680-0D-
68
500
F, G, J
CMR16E750-0D-
75
500
F, G, J
CMR16E820-0D-
82
500
F, G, J
CMR16F910-0D-
91
500
F, G, J
CMR16F101-0D-
100
500
F, G, J
CMR16F111-0D-
110
500
F, G, J
CMR16F121-0D-
120
500
F, G, J
CMR16F161-0D-
160
500
F, G, J
CMR16F151-0D-
150
500
F, G, J
CMR16F161-0D-
160
500
F, G, J
CMR16F181-0D-
180
500
F, G, J
CMR16F201-0D-
200
500
F, G, J
CMR16F221-0D-
220
500
F, G, J
CMR16F241-0D-
240
500
F, G, J
CMR16F271-0C-
270
600
F, G, J
CMR16F601-0C-
600
600
F, G, J
CMR16F661-0C-
660
600
F, G, J
CMR16F661-0C-
660
600
F, G, J
CMR16F691-0C-
690
600
F, G, J
CMR16F461-0A-
460
100
F, G, J
CMR16F471-0A-
470
100
F, G, J
CMR16F511-0A-
510
100
F, G, J
CMR16F561-0A-
560
100
F, G, J
CMR16F621-0A-
620
100
F, G, J
CMR16F681-0A-
680
100
F, G, J
1/ Complete type designation will include additional letter symbols to indicate the following,
where applicable:
Capacitance tolerance: D (±.5 pF); F ( ±1%); G (±2%); or J (±5%).
Failure rate level: M (1.0%); P (0.1%); R (0.01%); or S (0.001%).
Quality conformance test: 2,000 hours (M, P, R, and S FRLs) at +125°C and 150 percent of rated dc
voltage; requirements as specified for qualification.
Resistance to soldering heat: In accordance with MIL-PRF-39001 except DCap. shall not exceed
±1.5 percent of initial measurement or 1 pF, whichever is greater.
Marking: Capacitors shall be marked as indicated in figure 2.
Packaging:
Capacitors will be furnished in tape and reel packaging when so specified in the ordering data.
4
