MIL-PRF-39001/6A
FIGURE 2. Marking examples.
TABLE I. Type designations
STYLE CMR16
Type designation1/
Capacitance value
DC rated voltage
Capacitance tolerance available
(pF)
(volts)
CMR16C1R0D0D-
1.0
500
D
CMR16C1R5D0D-
1.5
500
D
CMR16C2R0D0D-
2.0
500
D
CMR16C2R5D0D-
2.5
500
D
CMR16C6R0D0D-
6.0
500
D
CMR16C6R5D0D-
6.5
500
D
CMR16C4R0D0D-
4.0
500
D
CMR16C4R5D0D-
4.5
500
D
CMR16C5R0D0D-
5.0
500
D
CMR16C6R0D0D-
6.0
500
D
CMR16C7R0D0D-
7.0
500
D
CMR16C8R0D0D-
8.0
500
D
CMR16C9R0D0D-
9.0
500
D
CMR16C100D0D-
10
500
D
CMR16C110-0D-
11
500
D, J
CMR16C120-0D-
12
500
D, J
CMR16C150-0D-
15
500
D, J
CMR16C180-0D-
18
500
D, J
CMR16E200-0D-
20
500
D, J
CMR16E220-0D-
22
500
D, J
CMR16E240-0D-
24
500
D, J
CMR16E270-0D-
27
500
G, J
CMR16E600-0D-
60
500
G, J
CMR16E660-0D-
66
500
G, J
CMR16E660-0D-
66
500
G, J
CMR16E690-0D-
69
500
G, J
CMR16E460-0D-
46
500
G, J
CMR16E470-0D-
47
500
G, J
See footnote at end of table.
3
