MIL-PRF-20M
TABLE X. Points read from tolerance envelope on figure 1.
Permissible capacitance change from capacitance at +25°C (ppm)
At -55°C
At -40°C
At -10°C
Characteristic
Max
Min
Max
Min
Max
Min
CG
4,300
-2,200
3,400
-1,900
1,700
-1,100
CH
7,300
-4,400
5,800
-3,700
2,900
-2,000
CJ
13,300
-9,300
10,500
-7,600
5,400
-4,200
CK
26,100
-19,700
20,800
-16,100
10,700
-8,600
At +45°C
At +65°C
At +85°C
At +125°C
Max
Min
Max
Min
Max
Min
Max
Min
CG
600
-700
1,100
-1,400
1,700
-1,800
3,000
-3,000
CH
1,300
-1,500
2,400
-2,500
3,600
-3,600
6,000
-6,000
CJ
2,300
-2,700
4,700
-5,100
7,200
-7,200
12,000
-12,000
CK
5,000
-5,500
10,000
-10,400
15,000
-15,000
25,000
-25,000
6.7 Subject term (key word) listing.
Capacitance
Parts per million
Statistical process control
6.8 Tin whisker growth. The use of alloys with tin content greater than 97 percent, by mass, may exhibit tin
whisker growth problems after manufacture. Tin whiskers may occur anytime from a day to years after manufacture
and can develop under typical operating conditions, on products that use such materials. Conformal coatings applied
over top of a whisker-prone surface will not prevent the formation of whiskers. Alloys of 3 percent lead, by mass,
have shown to inhibit the growth of tin whiskers. For additional information on this matter, refer to ASTM-B545
(Standard Specification for Electrodeposited Coatings of Tin).
6.9 Environmentally preferable material. Environmentally preferable materials should be used to the maximum
extent possible to meet the requirements of this specification. As of the dating of this document, the U.S.
Environmental Protection Agency (EPA) is focusing efforts on reducing 31 priority chemicals. The list of chemicals
and additional information is available on their website at https://www.epa.gov/osw/hazard/wastemin/priority.htm.
Included in the EPA list of 31 priority chemicals are cadmium, lead, and mercury. Use of these materials should be
minimized or eliminated unless needed to meet the requirements specified herein (see Section 3).
6.10 Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the Government
assumes no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal notations and
relationship to the last previous issue.
31
