MIL-PRF-19978K
1.2.1.5 Voltage. The dc voltage rating for continuous operation at the high ambient test temperature specified in
table III (except for characteristic K which is for +85C operation), is identified by a single letter in accordance with
table IV.
TABLE IV. DC voltage rating.
DC voltage rating 1/
DC voltage rating 1/
Symbol
Symbol
(Volts)
(Volts)
Z
30
K
2,500
A
50
L
3,000
B
100
M
4,000
C
200
N
5,000
D
300
P
6,000
E
400
R
7,500
F
600
S
10,000
G
1,000
T
12,500
H
1,500
U
15,000
J
2,000
1/ For characteristic K, voltage derating may be necessary at the high
ambient test temperature (see 3.1).
1.2.1.6 Capacitance. The nominal capacitance value expressed in picofarads (pF) is identified by a three-digit
number; the first two digits represent significant figures and the last digit specifies the number of zeros to follow.
1.2.1.7 Capacitance tolerance. The capacitance tolerance in percent is identified by a single letter in accordance
with table V.
TABLE V. Capacitance tolerance.
Capacitance tolerance
Symbol
percent ()
F
1
G
2
J
5
K
10
1.2.1.8 Vibration grade. The vibration grade is identified by a single digit in accordance with table VI.
TABLE VI. Vibration grade.
Symbol
Frequency range (Hz)
Acceleration (G)
1
10 to 55 inclusive
---
3
10 to 2,000 inclusive
15
1.2.1.9 Product level designator. The product level designation in percent per 1,000 hours is identified by a single
letter in accordance with table VII, and is based on rated voltage at the high test temperature, as applicable.
TABLE VII. Product level designator.
Product level
Symbol
(percent per 1,000 hours)
1.0
M
0.1
P
0.01
R
0.001
S
3
