MIL-PRF-19978/15A
TABLE III. Multimeter equivalent of decimal inches.
Inches
mm
Inches
mm
Inches
mm
Inches
mm
0.005
0.13
0.670
17.02
1.250
31.75
1.906
48.41
0.015
0.38
0.719
18.26
1.281
32.54
2.031
51.59
0.031
0.79
0.750
19.05
1.312
33.32
2.062
52.37
0.175
4.45
0.781
19.84
1.375
34.93
2.125
53.98
0.195
4.95
0.938
23.72
1.406
35.71
2.156
54.76
0.235
5.97
0.969
24.61
1.438
36.53
2.281
57.94
0.312
7.92
1.000
25.40
1.469
37.31
2.375
60.33
0.400
10.16
1.031
26.19
1.500
38.10
2.531
64.29
0.468
11.89
1.062
26.97
1.531
38.89
2.562
65.07
0.500
12.70
1.094
27.79
1.562
39.67
2.625
66.68
0.562
14.27
1.125
28.58
1.625
41.28
2.656
67.46
0.594
15.09
1.156
29.36
1.781
45.24
0.625
15.88
1.188
30.17
1.812
46.02
0.656
16.66
1.219
30.96
1.875
47.63
Terminal strength: Method 211 of MIL-STD-202, test condition letter D.
Dielectric absorption (not applicable to values of 0.01 F or less): 0.60 percent, maximum.
Stability at low and high temperature:
Low temperature:
Test temperature -65 C +0 C, -5 C.
Capacitance change (max) - -7 percent.
High temperature:
Test temperature - +85 C +5 C, -0 C.
Capacitance change (max) - +5 percent.
Life:
Capacitance change (max) -
5 percent of initial measured value.
Resistance to soldering heat: In accordance with MIL-PRF-19978.
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 11
(Project 5910-2016-11)
Review activities:
Navy - MC
Air Force - 19, 99
7
