MIL-PRF-19978/15A
TABLE I. Terminal-to-terminal insulation resistance.
Capacitance rating
Minimum insulation resistance
Characteristic M
At 25 C
0 to 0.68 microfarad
100,000 megohms
Greater than 0.68 microfarad
68,000 megohm-microfarads 1/
At 85 C
0 to 0.2 microfarad
25,000 megohms
Greater than 0.2 microfarad
5,000 megohm-microfarads 1/
1/
Product obtained by multiplying the capacitance in microfarads by the insulation
resistance in megohms.
TABLE II. Styles CQR33 capacitors.
Case dimensions
DC
Capacitance Capacitance
Failure
Circuit 1
Circuit 3
Part number 1/
voltage
rating
tolerance
rate
L .031 D +.015, L .031 D +.015,
rating
level
-.005
-.005
Volts
Inches
Inches
Inches
Inches
F
CQR33A-MZ155-3-
30
1.5
G, J, K
M, P, R, S
1.625
.562
1.531
.562
CQR33A-MZ225-3-
30
2.2
G, J, K
M, P, R, S
1.875
.670
1.781
.670
CQR33A-MZ335-3-
30
3.3
G, J, K
M, P, R, S
1.875
.750
1.781
.750
CQR33A-MZ475-3-
30
4.7
G, J, K
M, P, R, S
2.625
.750
2.531
.750
CQR33A-MZ685-3-
30
6.8
G, J, K
M, P, R, S
2.125
1.000
2.031
1.000
CQR33A-MZ106-3-
30
10.0
G, J, K
M, P, R, S
2.375
1.000
2.281
1.000
CQR33A-MA102-3-
50
.0010
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA122-3-
50
.0012
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA152-3-
50
.0015
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA182-3-
50
.0018
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA222-3-
50
.0022
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA272-3-
50
.0027
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA332-3-
50
.0033
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA392-3-
50
.0039
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA472-3-
50
.0047
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA562-3-
50
.0056
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA682-3-
50
.0068
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA822-3-
50
.0082
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA103-3-
50
.010
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA123-3-
50
.012
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA153-3-
50
.015
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA183-3-
50
.018
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA223-3-
50
.022
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA273-3-
50
.027
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA333-3-
50
.033
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA393-3-
50
.039
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA473-3-
50
.047
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA563-3-
50
.056
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA683-3-
50
.068
G, J, K
M, P, R, S
.594
.400
.562
.400
CQR33A-MA124-3-
50
.12
G, J, K
M, P, R, S
.875
.400
.781
.400
CQR33A-MA154-3-
50
.15
G, J, K
M, P, R, S
.875
.400
.781
.400
CQR33A-MA184-3-
50
.18
G, J, K
M, P, R, S
.875
.400
.781
.400
CQR33A-MA224-3-
50
.22
G, J, K
M, P, R, S
.875
.400
.781
.400
CQR33A-MA274-3-
50
.27
G, J, K
M, P, R, S
.875
.400
.781
.400
CQR33A-MA334-3-
50
.33
G, J, K
M, P, R, S
1.000
.400
.906
.400
See footnote at end of table.
