MIL-PRF-19978/1F
Immersion:
DWV:
Sleeving: In accordance with MIL-PRF-19978.
IR:
Sleeving: In accordance with MIL-PRF-19978.
Solderability: In accordance with MIL-PRF-19978.
Terminal strength: Method 211 of MIL-STD-202, test condition letter D.
Moisture resistance:
DWV:
Sleeving: In accordance with MIL-PRF-19978.
IR:
Sleeving: In accordance with MIL-PRF-19978.
Dielectric absorption (not applicable to values of 0.01 µF or less): See table I.
Stability at low and high temperatures:
Low temperature:
Characteristic
Test temperature
Capacitance change (max)
-65°C +0°C, -5°C
K
-10 percent
-65°C +0°C, -5°C
M
-7 percent
-65°C +0°C, -5°C
T
+5 percent
High temperature:
Characteristic
Test temperature
Capacitance change (max)
+125°C +5°, -0°C
K
+10 percent
+85°C +5°, -0°C
M
+5 percent
+170°C +5°, -0°C
T
-5 percent
Temperature coefficient (characteristic P only): In accordance with MIL-PRF-19978.
Life:
Capacitance change:
Capacitance change (max)
Characteristic
(of initial measured value)
K, M, and T
±5 percent
P (0.05 µF and less)
±6 percent
P (greater than 0.05 µF)
±3 percent
Resistance to soldering heat: In accordance with MIL-PRF-19978.
