MIL-DTL-3965/24C
Dimensions
Case
L 1/
D
E
±.016 (0.41)
±.250 (6.35)
size
+.031 (0.79)
Max
-.016 (0.41)
(CL66)
(CL67)
T1
.453 (11.51)
.188 (4.78)
.219 ( 5.56)
1.500 (38.10)
T2
.641 (16.28)
.281 (7.14)
.312 ( 7.92)
2.250 (57.15)
T3
.766 (19.46)
.375 (9.53)
.406 (10.31)
2.250 (57.15)
1/ For style CL67, nonshrinkable sleeving shall extend .016 inch minimum, .062 inch maximum, beyond
each end of the case; shrinkage sleeving shall lap over the ends of the case.
NOTES:
1. Dimensions are in inches.
2. Millimeters are in parentheses.
3. Metric equivalents (to the nearest .01 mm) are given for general information only.
FIGURE 1. Styles CL66 and CL67 capacitors Continued.
2
