MIL-DTL-3965/21F

Inches

.025

0.64

.412

10.46

.437

11.10

.625

15.88

.812

20.62

.875

22.23

.969

24.61

1.062

26.97

1.312

33.32

BRACKET FOR TYPE A CASE

Dimensions

Type

Case

Inches

Millimeters

Dim

Designation

Size

Min

Nom

Max

Min

Max

CL050SA13

.846

.862

.878

21.49

22.30

A2 1/

1.159

1.175

1.191

29.44

30.25

CL050SA33

1.409

1.425

1.441

35.79

36.60

A4 1/

1.784

1.800

1.816

45.31

46.13

A5 1/

2.284

2.300

2.316

58.01

58.82

1/ CL050SD13, CL050SD23 and CL050SD33 brackets (of MIL-DTL-3965/9) may be used for

case sizes A2, A4 and A5, respectively.

NOTES:

1. Dimensions are in inches.

2. Millimeters are in parentheses.

3. Metric equivalents are given for general information only.

4. Spade lugs shall be rigid (either double welded, double riveted, single riveted and soldered, or

single riveted and welded to the bracket).

5. Unless otherwise specified, tolerance is �.062 (1.157 mm).

FIGURE 3. CL050 brackets.
