TABLE I. Capacitor characteristics.
Dissi-
Voltage
DC leakage (max)
+25°C
+85°C
+125°C
PIN
Capac-
pation
Impedance
Dimensions L
Rated
Derated
Surge
±.062 (1.57)
(+85°C)
(+125°C)
(+85°C)
1/
tance
factor
(max)
(max)
µF
µA
µA
volts, dc
volts, dc
volts,dc
%
%
ohms
Inches
CL1-BC700TPG
8
7
9.2
70
53.0
6
30
48
60
.438(11.13)
CL1-BC141TPG
8
7
9.2
140
53.0
10
50
80
30
.562(14.27)
CL1-BD500TPG
10
9
11.5
50
37.5
5
25
40
75
.438(11.13)
CL1-BD101TPG
10
9
11.5
100
37.5
9
45
72
40
.562(14.27)
CL1-BF280TPG
20
18
23.0
28
21.4
6
30
48
85
.438(11.13)
CL1-BF560TPG
20
18
23.0
56
21.4
10
50
80
45
.562(14.27)
CL1-BH200TPG
30
26
34.5
20
15.0
7
35
56
125
.438(11.13)
CL1-BH400TPG
30
26
34.5
40
15.0
12
60
96
75
.562(14.27)
CL1-BK120TPG
60
52
69.0
12
9.1
7
35
56
180
.438(11.13)
CL1-BK250TPG
60
52
69.0
25
9.6
12
60
96
90
.562(14.27)
CL1-BM080TPG
90
78
103.0
8
6.1
7
35
56
250
.438(11.13)
CL1-BM160TPG
90
78
103.0
16
6.1
12
60
96
125
.562(14.27)
CL1-BR040TPG
180
155
207.0
4
6.1
7
35
56
500
.719(18.26)
CL1-BR080TPG
180
155
207.0
8
6.1
12
60
96
250
.938(23.83)
CL1-BS2R5TPG
270
235
310.0
2.5
5.7
7
35
56
750
1.031(26.19)
CL1-BS050TPG
270
235
310.0
5
5.7
11
55
88
375
1.375(34.93)
CL1-BT020TPG
360
310
414.0
2
6.1
7
35
56
1,000
1.312(33.32)
CL1-BT040TPG
360
310
414.0
4
6.1
12
60
96
500
1.781(45.24)
1/ Complete type designation will include an additional symbol to indicate style.
