TABLE I. Capacitor characteristics.
Dissi-
Voltage
DC leakage (max)
PIN
pation
Imped-
Dimension L
Capaci-
+25°C
+85°C
+125°C
Rated
Derated
Surge
±.062 (1.57)
1/
factor
ance
tance
(+85°C)
(+125°C)
(+85°C)
(max)
(max)
µF
µA
µA
µA
volts, dc
volts, dc
volts,dc
%
ohms
Inches
CL1-BF101UPG
20
18
23.0
100.0
10
50
80
21.0
30
.540 (13.72)
CL1-BF201UPG
20
18
23.0
200.0
16
80
128
36.0
20
.732 (18.59)
CL1-BH750UPG
30
26
34.5
75.0
11
55
88
15.0
45
.540 (13.72)
CL1-BH151UPG
30
26
34.5
150.0
13
90
104
29.0
30
.732 (18.59)
CL1-BK400UPG
60
52
69.0
40.0
12
60
96
8.2
65
.540 (13.72)
CL1-BK800UPG
60
52
69.0
80.0
19
95
152
16.0
35
.732 (18.59)
CL1-BM250UPG
90
78
103.0
25.0
11
55
88
5.1
90
.540 (13.72)
CL1-BM500UPG
90
78
103.0
50.0
18
90
144
10.0
45
.732 (18.59)
CL1-BR120UPG
180
155
207.0
12.0
11
55
88
5.1
180
.920 (23.37)
CL1-BR250UPG
180
155
207.0
25.0
18
90
144
10.0
90
1.300 (33.02)
CL1-BS080UPG
270
235
310.0
8.0
11
55
88
5.1
270
1.270 (32.36)
CL1-BS160UPG
270
235
310.0
16.0
18
90
144
10.0
135
1.865 (47.37)
CL1-BT060UPG
360
310
414.0
6.0
11
55
88
5.0
360
1.635 (41.53)
CL1-BT120UPG
360
310
414.0
12.0
18
90
144
10.0
180
2.420 (61.47)
CL1-BU050UPG
450
390
518.0
5.0
11
55
88
4.9
450
2.000 (50.80)
CL1-BU100UPG
450
390
518.0
10.0
18
90
144
9.8
225
2.980 (75.69)
CL1-BV040UPG
540
470
621.0
4.0
11
55
88
5.1
540
2.365 (60.07)
CL1-BV080UPG
540
470
621.0
8.0
18
90
144
10.0
270
3.532 (89.71)
CL1-BW3R5UPG
630
545
724.0
3.5
11
55
88
5.0
630
2.720 (69.09)
CL1-BW070UPG
630
545
724.0
7.0
18
90
144
10.0
315
4.062(103.17)
1/ Complete type designation will include an additional symbol to indicate style.
