MIL-C-19978/16B
TABLE I. Styles CQR39 capacitors - Continued.
Capacitance
Failure
Part or
DC voltage
Case dimensions (inches) 2/ 3/
(µF)
rate level
Identifying
rating
Circuit 1
Circuit 3
Number (PIN) 1/
(volts)
L ±.031
D+.015 L ±.031
D+.015
-.005
-.005
CQR39A-KC824K3-
200
.82
M, P, R, S
2.125
0.750
2.062
0.750
CQR39A-KC105K3-
200
1.0
M, P, R, S
2.125
0.750
2.062
0.750
CQR39A-KE272K3-
400
.0027
M, P, R, S
0.750
0.235
0.688
0.235
CQR39A-KE332K3-
400
.0033
M, P, R, S
0.750
0.235
0.688
0.235
CQR39A-KE123K3-
400
.012
M, P, R, S
0.875
0.312
0.812
0.312
CQR39A-KE153K3-
400
.015
M, P, R, S
0.875
0.312
0.812
0.312
CQR39A-KE273K3-
400
.027
M, P, R, S
0.875
0.400
0.812
0.400
CQR39A-KE333K3-
400
.033
M, P, R, S
0.875
0.400
0.812
0.400
CQR39A-KE393K3-
400
.039
M, P, R, S
1.125
0.400
1.062
0.400
CQR39A-KE473K3-
400
.047
M, P, R, S
1.125
0.400
1.062
0.400
CQR39A-KE563K3-
400
.056
M, P, R, S
1.375
0.400
1.312
0.400
CQR39A-KE683K3-
400
.068
M, P, R, S
1.375
0.400
1.312
0.400
CQR39A-KE823K3-
400
.082
M, P, R, S
1.125
0.562
1.062
0.562
CQR39A-KE104K3-
400
.10
M, P, R, S
1.125
0.562
1.062
0.562
CQR39A-KE124K3-
400
.12
M, P, R, S
1.375
0.562
1.312
0.562
CQR39A-KE154K3-
400
.15
M, P, R, S
1.375
0.562
1.312
0.562
CQR39A-KE184K3-
400
.18
M, P, R, S
1.625
0.562
1.562
0.562
CQR39A-KE224K3-
400
.22
M, P, R, S
1.625
0.562
1.562
0.562
CQR39A-KE274K3-
400
.27
M, P, R, S
1.625
0.670
1.562
0.670
CQR39A-KE334K3-
400
.33
M, P, R, S
1.625
0.670
1.562
0.670
CQR39A-KE394K3-
400
.39
M, P, R, S
2.125
0.750
2.062
0.750
CQR39A-KE474K3-
400
.47
M, P, R, S
2.125
0.750
2.062
0.750
CQR39A-KF102K3-
600
.0010
M, P, R, S
0.750
0.235
0.688
0.235
CQR39A-KF122K3-
600
.0012
M, P, R, S
0.750
0.235
0.688
0.235
CQR39A-KF152K3-
600
.0015
M, P, R, S
0.750
0.235
0.688
0.235
CQR39A-KF182K3-
600
.0018
M, P, R, S
0.750
0.235
0.688
0.235
CQR39A-KF222K3-
600
.0022
M, P, R, S
0.750
0.235
0.688
0.235
CQR39A-KF272K3-
600
.0027
M, P, R, S
0.875
0.312
0.812
0.312
CQR39A-KF332K3-
600
.0033
M, P, R, S
0.875
0.312
0.812
0.312
CQR39A-KF392K3-
600
.0039
M, P, R, S
0.875
0.312
0.812
0.312
CQR39A-KF472K3-
600
.0047
M, P, R, S
0.875
0.312
0.812
0.312
CQR39A-KF562K3-
600
.0056
M, P, R, S
0.875
0.312
0.812
0.312
CQR39A-KF682K3-
600
.0068
M, P, R, S
0.875
0.312
0.812
0.312
CQR39A-KF822K3-
600
.0082
M, P, R, S
0.875
0.312
0.812
0.312
CQR39A-KF103K3-
600
.010
M, P, R, S
0.875
0.312
0.812
0.312
CQR39A-KF123K3-
600
.012
M, P, R, S
0.875
0.400
0.812
0.400
CQR39A-KF153K3-
600
.015
M, P, R, S
0.875
0.400
0.812
0.400
CQR39A-KF183K3-
600
.018
M, P, R, S
0.875
0.400
0.812
0.400
CQR39A-KF223K3-
600
.022
M, P, R, S
0.875
0.400
0.812
0.400
CQR39A-KF273K3-
600
.027
M, P, R, S
1.125
0.400
1.062
0.400
CQR39A-KF333K3-
600
.033
M, P, R, S
1.125
0.400
1.062
0.400
CQR39A-KF393K3-
600
.039
M, P, R, S
1.375
0.400
1.312
0.400
CQR39A-KF473K3-
600
.047
M, P, R, S
1.375
0.400
1.312
0.400
CQR39A-KF563K3-
600
.056
M, P, R, S
1.125
0.562
1.062
0.562
CQR39A-KF683K3-
600
.068
M, P, R, S
1.125
0.562
1.062
0.562
CQR39A-KF823K3-
600
.082
M, P, R, S
1.375
0.562
1.312
0.562
CQR39A-KF104K3-
600
.10
M, P, R, S
1.375
0.562
1.312
0.562
CQR39A-KF124K3-
600
.12
M, P, R, S
1.625
0.562
1.562
0.562
CQR39A-KF154K3-
600
.15
M, P, R, S
1.625
0.562
1.562
0.562
See footnotes at end of table.
3
