MIL-C-11015/25C
REQUIREMENTS
Design and construction:
Dimensions and configuration - See figure 1.
Case type - Tubular with axial leads.
Capacitance value - See table I.
Capacitance tolerance -
5 percent (J), 10 percent (K), or 20 percent (M) as specified in table I.
Rated temperature - -55 C to +125 C.
Dielectric withstanding voltage (DWV): In accordance with MIL-C-11015.
Dielectric:
Test voltage - 250 percent of dc working voltage.
Body insulation: Not applicable.
Barometric pressure (reduced): In accordance with MIL-C-11015 and method 105 of MIL-STD-202, 0.82 inch of
mercury (80,000 feet).
Test potential - 150 percent of rated voltage.
Insulation resistance (IR): In accordance with MIL-C-11015, rated voltage applied.
100,000 megohms, minimum, or 1,000 megohm-microfarads, minimum, whichever is less.
Dissipation factor (DF): 1.0 percent max for voltage-temperature limit BT
1.5 percent max for voltage-temperature limit BU
3.0 percent max for voltage-temperature limit BV
TABLE II. Voltage-temperature limits
Voltage-temperature limits (%)
capacitance change with reference to 25 C.
Voltage-temperature
Steps A to D, inclusive
Steps E to G, inclusive
symbol
of table VIII (%)
of table VIII (%)
+2, -10
+2, -10
T
+2, -15
+2, -15
U
+20, -50
+20, -45
V
Vibration, high frequency: In accordance with MIL-C-11015 and method 204 of MIL-STD-202, condition D (20 G's).
Thermal shock and immersion: In accordance with MIL-C-11015.
Immersion:
DWV - 250 percent of rated voltage.
IR - 10,000 megohms, minimum, or 100 megohm-microfarads, whichever is less.
Cap. - Change not more than 2 percent for voltage-temperature limits BT and BU, and 5 percent for
voltage-temperature limit BV.
DF - Not greater than initial requirement.
