INCH-POUND
MIL-C-11015/25C
14 May 2001
SUPERSEDING
MIL-C-11015/25B(USAF)
6 JULY 1976
MILITARY SPECIFICATION SHEET
CAPACITORS, FIXED, CERAMIC DIELECTRIC (GENERAL PURPOSE),
STYLE CK31 AND CK32
The requirements for acquiring the capacitors described herein
shall consist of this specification and MIL-C-11015.
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
INACTIVE FOR NEW DESIGN AFTER 6 JULY 1977. STYLES
CK31....TX and CK32....TX PARTS CANCELLED AFTER 14 MAY 2001.
USE MIL-PRF-39014/21, STYLES CKR31 AND CKR32.
Dimensions
L
D
Style
Inches
mm
Inches
mm
Min
Max
Min
Max
Min
Max
Min
Max
CK31
.230
.250
5.84
6.35
.080
.100
2.03
2.54
CK32
.230
.250
5.84
6.35
.120
.140
3.05
3.56
NOTES
1. All dimensions are in inches.
2. Millimeters are in parentheses.
3. Metric equivalents (to the nearest .01 mm) are given for general information only.
FIGURE 1. Styles CK31 and CK32 capacitors.
AMSC N/A
1 of 4
FSC 5910
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
