MIL-PRF-55681/6A
TABLE I. Capacitor characteristics - Continued.
PIN 1/
Capacitance
Capacitance
Rated temperature
pF
tolerance
and voltage-
temperature limits
4,000 V dc
CDR26BP151J - - -
150
F, G, J
BP
CDR27BP271J - - -
270
F, G, J
BP
CDR27BP331J - - -
330
F, G, J
BP
CDR28BP391J - - -
390
F, G, J
BP
CDR28BP471J - - -
470
F, G, J
BP
CDR28BP561J - - -
560
F, G, J
BP
CDR28BP681J - - -
680
F, G, J
BP
CDR29BP821J - - -
820
F, G, J
BP
CDR29BP102J - - -
1,000
F, G, J
BP
CDR29BP122J - - -
1,200
F, G, J
BP
CDR30BP152J - - -
1,500
F, G, J
BP
CDR30BP182J - - -
1,800
F, G, J
BP
CDR30BP222J - - -
2,200
F, G, J
BP
CDR26BX151J - - -
150
K, M
BX
CDR26BX181J - - -
180
K, M
BX
CDR26BX221J - - -
220
K, M
BX
CDR26BX271J - - -
270
K, M
BX
CDR26BX331J - - -
330
K, M
BX
CDR26BX391J - - -
390
K, M
BX
CDR26BX471J - - -
470
K, M
BX
CDR27BX561J - - -
560
K, M
BX
CDR27BX681J - - -
680
K, M
BX
CDR27BX821J - - -
820
K, M
BX
CDR27BX102J - - -
1,000
K, M
BX
CDR27BX122J - - -
1,200
K, M
BX
CDR28BX152J - - -
1,500
K, M
BX
CDR28BX182J - - -
1,800
K, M
BX
CDR28BR222J - - - 2/
2,200
K, M
BR
CDR29BX272J - - -
2,700
K, M
BX
CDR29BR332J - - - 2/
3,300
K, M
BR
CDR29BR392J - - - 2/
3,900
K, M
BR
1/ Complete PIN shall include additional symbols to indicate capacitance tolerance,
termination finish, and product level.
2/ With respect to rated temperature and voltage-temperature limits in the original issue of
this specification sheet: BR is interchangeable with BX. These parts shall be stocked
under the same applicable NSN's.
3/ With respect to rated temperature and voltage-temperature limits in the original issue of
this specification sheet: BZ is interchangeable with BX. These parts shall be stocked
under the same applicable NSN's.
