MIL-PRF-55681/4G
TABLE I. Styles CDR11 and CDR12 capacitor characteristics - Continued.
Rated temperature
Rated voltage
Capacitance
Capacitance
PIN 1/ 2/
and voltage-
(V dc)
(pF)
tolerance
temperature limits
CDR1-B-300 - - - -
30
F, G, J, K, M
BG, BP
50, 150
CDR1-B-330 - - - -
33
F, G, J, K, M
BG, BP
50, 150
CDR1-B-360 - - - -
36
F, G, J, K, M
BG, BP
50, 150
CDR1-B-390 - - - -
39
F, G, J, K, M
BG, BP
50, 150
CDR1-B-430 - - - -
43
F, G, J, K, M
BG, BP
50, 150
CDR1-B-470 - - - -
47
F, G, J, K, M
BG, BP
50, 150
CDR1-B-510 - - - -
51
F, G, J, K, M
BG, BP
50, 150
CDR1-B-560 - - - -
56
F, G, J, K, M
BG, BP
50, 150
CDR1-B-620 - - - -
62
F, G, J, K, M
BG, BP
50, 150
CDR1-B-680 - - - -
68
F, G, J, K, M
BG, BP
50, 150
CDR1-B-750 - - - -
75
F, G, J, K, M
BG, BP
50, 150
CDR1-B-820 - - - -
82
F, G, J, K, M
BG, BP
50, 150
CDR1-B-910 - - - -
91
F, G, J, K, M
BG, BP
50, 150
CDR1-B-101 - - - -
100
F, G, J, K, M
BG, BP
50, 150
CDR1-BP111A - - -
110
F, G, J, K, M
BP
50, 100
CDR1-BP121A - - -
120
F, G, J, K, M
BP
50, 100
CDR1-BP131A - - -
130
F, G, J, K, M
BP
50, 100
CDR1-BP151A - - -
150
F, G, J, K, M
BP
50, 100
CDR1-BP161A - - -
160
F, G, J, K, M
BP
50, 100
CDR1-BP181A - - -
180
F, G, J, K, M
BP
50, 100
CDR1-BP201A - - -
200
F, G, J, K, M
BP
50, 100
CDR1-BP221A - - -
220
F, G, J, K, M
BP
50, 100
CDR1-BP241A - - -
240
F, G, J, K, M
BP
50, 100
CDR1-BP271A - - -
270
F, G, J, K, M
BP
50, 100
CDR1-BP301A - - -
300
F, G, J, K, M
BP
50, 100
CDR1-BP331A - - -
330
F, G, J, K, M
BP
50, 100
CDR1-BP361A - - -
360
F, G, J, K, M
BP
50, 100
CDR1-BP391A - - -
390
F, G, J, K, M
BP
50, 100
CDR1-BP431A - - -
430
F, G, J, K, M
BP
50, 100
CDR1-BP471A - - -
470
F, G, J, K, M
BP
50, 100
CDR1-BP511A - - -
510
F, G, J, K, M
BP
50, 100
CDR1-BP561A - - -
560
F, G, J, K, M
BP
50, 100
CDR1-BP621A - - -
620
F, G, J, K, M
BP
50, 100
CDR1-BP681A - - -
680
F, G, J, K, M
BP
50, 100
CDR1-BP751A - - -
750
F, G, J, K, M
BP
50, 100
CDR1-BP821A - - -
820
F, G, J, K, M
BP
50, 100
CDR1-BP911A - - -
910
F, G, J, K, M
BP
50, 100
CDR1-BP102A - - -
1,000
F, G, J, K, M
BP
50, 100
1/ Complete PIN shall include additional symbols to indicate style, voltage-temperature limits (where applicable),
rated voltage, capacitance tolerance (where applicable), termination finish ("M" or "N" for style CDR11, and "S",
"U", "W", "Y" or "Z" for style CDR12), and product level.
2/ All capacitors with the 150 volt rating (rated voltage code letter "K") are substitutable, with acquiring agency
approval, for the same capacitors which had the 50 volt rating (rated voltage code letter "A") in previous revisions
of this document.
4
