MIL-PRF-55681/3E
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Capacitance value: See table I.
Capacitance tolerance: J = ±5 percent, K = ±10 percent, M = ±20 percent. See table I.
Rated voltage: See table I.
Product level designator: Non-established Reliability - C; Established Reliability - M, P, R, S.
Operating temperature range: -55° C to +125° C.
Marking: In accordance with MIL-PRF-55681.
TABLE I. Capacitor characteristics.
Capacitance
Part or Identifying
Capacitance
Rated temperature
Rated
Number (PIN) 1/
(pF)
tolerance
and voltage
voltage
temperature limits
(V dc)
CDR06BP682B - - -
6,800
J, K
BP
100
CDR06BP822B - - -
8,200
J, K
BP
100
CDR06BP103B - - -
10,000
J, K
BP
100
CDR06BX394AK - -
390,000
K
BX
50
CDR06BX474A - - -
470,000
K, M
BX
50
1/ Complete PIN shall include additional symbols to indicate capacitance tolerance (where applicable),
termination finish, and product level.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government assumes
no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
Custodians:
Preparing activity:
Army - CR
Army - CR
Navy - EC
Air Force - 11
Agent:
DLA - CC
DLA - CC
Review activities:
Navy - AS, MC, OS, SH
(Project 5910-2006-049)
Air Force - 19, 99
