MIL-PRF-55681/2D
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Capacitance value: See table I.
Capacitance tolerance: J = ±5 percent; K = ±10 percent; M = ±20 percent. See table I.
Rated voltage: See table I.
Product level designator: Non-established Reliability - C; Established Reliability - M, P, R, and S.
Operating temperature range: -55°C to +125°C.
Marking: In accordance with MIL-PRF-55681.
TABLE I. Capacitor characteristics.
Part or Identifying
Capacitance
Capacitance
Rated temperature
Rated
and voltage
voltage
Number (PIN) 1/
(pF)
tolerance
temperature limits
(V dc)
CDR05BP392B - - -
3,900
J, K
BP
100
CDR05BP472B - - -
4,700
J, K
BP
100
CDR05BP562B - - -
5,600
J, K
BP
100
CDR05BX683B - - -
68,000
K, M
BX
100
CDR05BX823BK - -
82,000
K
BX
100
CDR05BX104B - - -
100,000
K, M
BX
100
CDR05BX124BK - -
120,000
K
BX
100
CDR05BX154B - - -
150,000
K, M
BX
100
CDR05BX224A - - -
220,000
K, M
BX
50
CDR05BX274AK - -
270,000
K
BX
50
CDR05BX334A - - -
330,000
K, M
BX
50
1/ Complete PIN shall include additional symbols to indicate capacitance tolerance
(where applicable), termination finish, and product level.
CHANGES FROM PREVIOUS ISSUE: The margins of this specification sheet are marked with asterisks
to indicate where changes from the previous issue were made. This was done as a convenience only and
the Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
2
