INCH-POUND
MIL-PRF-55681/2D
11 October 2006
SUPERSEDING
MIL-PRF-55681/2C
3 July 1997
PERFORMANCE SPECIFICATION SHEET
CAPACITORS, CHIP, MULTIPLE LAYER, FIXED, CERAMIC DIELECTRIC,
ESTABLISHED RELIABILITY AND NON-ESTABLISHED RELIABILITY,
STYLE CDR05
This specification is approved for use by all Departments and Agencies
of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-55681.
Inches
mm
.010
0.25
.015
0.38
.020
0.51
.080
2.03
.180
4.57
.250
6.35
Dimensions
L +.020
W +.020
T
-.015
-.015
Min
Max
.180
.250
.020
.080
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Dimensions and tolerances are for bare chips. For solder coated terminations, add .025 inch (0.64
mm) to the positive length tolerance and .015 inch (0.38 mm) to the positive width and thickness
tolerances.
FIGURE 1. Dimensions and configuration.
AMSC N/A
FSC 5910
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
