INCH-POUND
MIL-PRF-55681/1F
11 October 2006
SUPERSEDING
MIL-PRF-55681/1E
17 February 2000
PERFORMANCE SPECIFICATION SHEET
CAPACITORS, CHIP, MULTIPLE LAYER, FIXED, CERAMIC DIELECTRIC,
ESTABLISHED RELIABILITY AND NON-ESTABLISHED RELIABILITY,
STYLES CDR01, CDR02, CDR03, AND CDR04
This specification is approved for use by all Departments and Agencies
of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-55681.
Inches
mm
.010
0.25
.015
0.38
.020
0.51
.025
0.64
.030
0.76
Dimensions
L ± .015 (0.38)
W ± .015 (0.38)
Style
T
Min
Max
CDR01
.080 (2.03)
.050 (1.27)
.022 (0.56)
.055 (1.40)
CDR02
.180 (4.57)
.050 (1.27)
.022 (0.56)
.055 (1.40)
CDR03
.180 (4.57)
.080 (2.03)
.022 (0.56)
.080 (2.03)
CDR04
.180 (4.57)
.125 (3.18)
.022 (0.56)
.080 (2.03)
FIGURE 1. Styles CDR01, CDR02, CDR03, and CDR04 capacitors
AMSC N/A
FSC 5910
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
