MIL-PRF-55514/8G
*
TABLE I. Styles CFR12 and CFR16 capacitor characteristics.
Style CFR12 1/
Rated
Type designation 2/
Capacitance
Capacitance
voltage
tolerance
(µF)
at +85°C
(volts)
F, G, J, K
50
.033
CFR12R-A333--
F, G, J, K
50
.039
CFR12R-A393--
F, G, J, K
50
.047
CFR12R-A473--
F, G, J, K
50
.056
CFR12R-A563--
F, G, J, K
75
.022
CFR12R-G223--
F, G, J, K
75
.027
CFR12R-G273--
F, G, J, K
100
.010
CFR12R-B103--
F, G, J, K
100
.012
CFR12R-B123--
F, G, J, K
100
.015
CFR12R-B153--
F, G, J, K
100
.018
CFR12R-B183--
F, G, J, K
150
.0068
CFR12R-H682--
F, G, J, K
150
.0082
CFR12R-H822--
F, G, J, K
200
.0039
CFR12R-C392--
F, G, J, K
200
.0047
CFR12R-C472--
F, G, J, K
200
.0056
CFR12R-C562--
F, G, J, K
250
.0010
CFR12R-K102--
F, G, J, K
250
.0012
CFR12R-K122--
F, G, J, K
250
.0015
CFR12R-K152--
F, G, J, K
250
.0018
CFR12R-K182--
F, G, J, K
250
.0022
CFR12R-K222--
F, G, J, K
250
.0027
CFR12R-K272--
F, G, J, K
250
.0033
CFR12R-K332--
Style CFR16
Type designation 2/
Capacitance
Rated
Capacitance
T
H
L
L. S.
voltage at
tolerance
(µF)
±.010
±.020
±.010
±.015
+85°C
(0.25)
(0.51)
(0.25)
(0.38)
(volts)
.200 (5.08)
.295 (7.49)
.245 (6.22)
.095 (2.41)
F, G, J, K
50
.068
CFR16R-A683--
.200 (5.08)
.295 (7.49)
.245 (6.22)
.095 (2.41)
F, G, J, K
50
.082
CFR16R-A823--
.200 (5.08)
.295 (7.49)
.245 (6.22)
.095 (2.41)
F, G, J, K
50
.10
CFR16R-A104--
.200 (5.08)
.295 (7.49)
.295 (7.49)
.095 (2.41)
F, G, J, K
50
.12
CFR16R-A124--
.200 (5.08)
.295 (7.49)
.295 (7.49)
.095 (2.41)
F, G, J, K
50
.15
CFR16R-A154--
.200 (5.08)
.295 (7.49)
.295 (7.49)
.095 (2.41)
F, G, J, K
50
.18
CFR16R-A184--
.300 (7.62)
.395 (10.03)
.395 (10.03)
.095 (2.41)
F, G, J, K
50
.22
CFR16R-A224--
.300 (7.62)
.395 (10.03)
.395 (10.03)
.095 (2.41)
F, G, J, K
50
.27
CFR16R-A274--
.300 (7.62)
.395 (10.03)
.395 (10.03)
.095 (2.41)
F, G, J, K
50
.33
CFR16R-A334--
.300 (7.62)
.395 (10.03)
.395 (10.03)
.095 (2.41)
F, G, J, K
50
.39
CFR16R-A394--
.300 (7.62)
.395 (10.03)
.395 (10.03)
.145 (3.68)
F, G, J, K
50
.47
CFR16R-A474--
.300 (7.62)
.395 (10.03)
.395 (10.03)
.145 (3.68)
F, G, J, K
50
.56
CFR16R-A564--
.300 (7.62)
.395 (10.03)
.395 (10.03)
.195 (4.95)
F, G, J, K
50
.78
CFR16R-A684--
.300 (7.62)
.395 (10.03)
.395 (10.03)
.195 (4.95)
F, G, J, K
50
.82
CFR16R-A824--
.300 (7.62)
.395 (10.03)
.395 (10.03)
.195 (4.95)
F, G, J, K
50
1.00
CFR16R-A105--
1/ Application note: Care must be taken during wave soldering to assure that the CFR12 type capacitors are not
damaged due to overheating. During the wave soldering operation, the CFR12 type capacitor shall not be
exposed to conditions in excess of the resistance to solder heat requirements of MIL-PRF-55514.
*
2/ The complete type designation will include additional symbols to indicate characteristic (U or R), capacitance
tolerance (F, G, J, or K), and product level (C, M, P, R, or S).
4
