TABLE I. Capacitor characteristics - Continued.
75 VDC
AC ratings (for sinusoidal operation
Dimensions (in inches)
from -55°C to +105°C) 3/
Part or Indentifying
Capacitance
Capacitance
Number (PIN) 1/
(nom)
tolerance
RMS current
RMS voltage - Volts
D ± .050 (1.27)
L ± .050 (1.27)
µF
M 2/
available
Amperes
0-400 Hz
4 kHz
CFR09AUG333--
.033
F,G,J,K
.170 (4.32)
.400 (10.16)
.020 (0.51)
.140
39.0
39.0
CFR09AUG393--
.039
F,G,J,K
.170 (4.32)
.400 (10.16)
.020 (0.51)
.168
39.0
39.0
CFR09AUG473--
.047
F,G,J,K
.190 (4.83)
.400 (10.16)
.020 (0.51)
.200
39.0
39.0
CFR09AUG563--
.056
F,G,J,K
.190 (4.83)
.400 (10.16)
.020 (0.51)
.240
39.0
39.0
CFR09AUG683--
.068
F,G,J,K
.230 (5.84)
.400 (10.16)
.025 (0.64)
.288
39.0
39.0
CFR09AUG823--
.082
F,G,J,K
.230 (5.84)
.400 (10.16)
.025 (0.64)
.384
39.0
39.0
CFR09AUG104--
.10
F,G,J,K
.260 (6.60)
.400 (10.16)
.025 (0.64)
.424
39.0
37.0
CFR09AUG124--
.12
F,G,J,K
.260 (6.60)
.400 (10.16)
.025 (0.64)
.512
39.0
35.0
CFR09AUG154--
.15
F,G,J,K
.230 (5.84)
.530 (13.46)
.025 (0.64)
.276
39.0
33.0
CFR09AUG184--
.18
F,G,J,K
.230 (5.84)
.530 (13.46)
.025 (0.64)
.328
39.0
31.0
CFR09AUG224--
.22
F,G,J,K
.260 (6.60)
.530 (13.46)
.025 (0.64)
.404
39.0
29.0
CFR09AUG274--
.27
F,G,J,K
.260 (6.60)
.530 (13.46)
.025 (0.64)
.496
39.0
27.0
CFR09AUG334--
.33
F,G,J,K
.310 (7.87)
.530 (13.46)
.025 (0.64)
.604
39.0
25.0
CFR09AUG394--
.39
F,G,J,K
.310 (7.87)
.530 (13.46)
.025 (0.64)
.716
39.0
24.0
CFR09AUG474--
.47
F,G,J,K
.350 (8.89)
.530 (13.46)
.025 (0.64)
1.290
39.0
22.5
CFR09AUG564--
.56
F,G,J,K
.310 (7.87)
.750 (19.05)
.025 (0.64)
.652
39.0
21.0
CFR09AUG684--
.68
F,G,J,K
.310 (7.87)
.750 (19.05)
.025 (0.64)
.792
39.0
19.0
CFR09AUG824--
.82
F,G,J,K
.350 (8.89)
.750 (19.05)
.025 (0.64)
1.212
39.0
17.5
CFR09AUG105--
1.0
F,G,J,K
.350 (8.89)
.750 (19.05)
.025 (0.64)
1.434
39.0
16.0
CFR09AUG125--
1.2
F,G,J,K
.400 (10.16)
.750 (19.05)
.025 (0.64)
1.770
39.0
15.0
CFR09AUG155--
1.5
F,G,J,K
.350 (8.89)
1.030 (26.16)
.025 (0.64)
1.374
39.0
14.0
CFR09AUG185--
1.8
F,G,J,K
.400 (10.16)
1.030 (26.16)
.025 (0.64)
1.818
39.0
13.0
CFR09AUG205--
2.0
F,G,J,K
.400 (10.16)
1.030 (26.16)
.025 (0.64)
1.830
39.0
12.5
CFR09AUG225--
2.2
F,G,J,K
.400 (10.16)
1.030 (26.16)
.025 (0.64)
2.010
39.0
12.0
CFR09AUG275--
2.7
F,G,J,K
.440 (11.18)
1.030 (26.16)
.032 (0.81)
2.466
39.0
11.5
CFR09AUG305--
3.0
F,G,J,K
.490 (12.45)
1.030 (26.16)
.032 (0.81)
2.742
39.0
11.0
CFR09AUG335--
3.3
F,G,J,K
.490 (12.45)
1.030 (26.16)
.032 (0.81)
3.018
39.0
10.5
CFR09AUG395--
3.9
F,G,J,K
.560 (14.22)
1.030 (26.16)
.032 (0.81)
3.942
39.0
10.0
CFR09AUG475--
4.7
F,G,J,K
.560 (14.22)
1.030 (26.16)
.032 (0.81)
4.000
39.0
9.0
CFR09AUG505--
5.0
F,G,J,K
.560 (14.22)
1.250 (31.75)
.032 (0.81)
3.558
39.0
8.5
CFR09AUG565--
5.6
F,G,J,K
.560 (14.22)
1.250 (31.75)
.032 (0.81)
3.984
39.0
8.0
CFR09AUG685--
6.8
F,G,J,K
.610 (15.49)
1.250 (31.75)
.032 (0.81)
4.000
39.0
7.0
CFR09AUG825--
8.2
F,G,J,K
.670 (17.02)
1.250 (31.75)
.032 (0.81)
4.000
39.0
6.5
CFR09AUG106--
10.0
F,G,J,K
.670 (17.02)
1.500 (38.10)
.032 (0.81)
4.000
39.0
5.5
CFR09AUG126--
12.0
F,G,J,K
.740 (18.80)
1.500 (38.10)
.032 (0.81)
4.000
39.0
4.5
CFR09AUG156--
15.0
F,G,J,K
.740 (18.80)
1.500 (38.10)
.032 (0.81)
4.000
37.0
3.5
See footnotes at end of table.
