MIL-PRF-55365/4J
L
W
H
P
Case size
± .015 (0.38) ±.015 (0.38)
±.015 (0.38)
±.005 (0.13)
A
.100 (2.54)
.050 (1.27)
.050 (1.27)
.030 (0.76)
B
.150 (3.81)
.050 (1.27)
.050 (1.27)
.030 (0.76)
C
.200 (5.08)
.050 (1.27)
.050 (1.27)
.030 (0.76)
D
.150 (3.81)
.100 (2.54)
.050 (1.27)
.030 (0.76)
E
.200 (5.08)
.100 (2.54)
.050 (1.27)
.030 (0.76)
F
.220 (5.59)
.135 (3.43)
.070 (1.78)
.030 (0.76)
G
.265 (6.73)
.110 (2.79)
.110 (2.79)
.050 (1.27)
H
.285 (7.24)
.150 (3.81)
.110 (2.79)
.050 (1.27)
X
.273 (6.93)
.213 (5.41)
.108 (2.74)
.047 (1.19)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Metric equivalents are in parentheses.
4. These capacitors are designed for mounting by dip soldering, thermo-compression bonding, reflow soldering, or
other conventional means.
5. Cathode terminal may be epoxy coated on one surface for polarity identification.
6. Solderable surfaces are only those surfaces designated as such.
7. Anode and cathode terminals may be two-sided through five-sided, and may not be the same on some designs,
but will meet all specification requirements.
8. The anode terminal shall be identified by the riser wire connection, which may extend the case size .015 inch
(0.38 mm) maximum. The riser wire weld area is not solderable. The riser wire connection shall have a
continuous weld of a minimum of 25 percent of the contact surface.
9. When solder coated terminations are required, add an additional .015 inch (0.38 mm) to the above listed
tolerances for "L", "W", "H", and "P" for each case size.
FIGURE 1. Style CWR06 (conformally coated) capacitors - Continued.
