MIL-PRF-39022/1G
TABLE III. Metric equivalents of decimal inches. 1/
Inches
mm
Inches
mm
Inches
mm
.031
0.79
.750
19.05
1.688
42.88
.062
1.57
.781
19.84
1.750
44.45
.175
4.45
.812
20.62
1.781
45.24
.195
4.95
.844
21.44
1.812
46.02
.235
5.97
.875
22.23
1.844
46.84
.312
7.92
1.000
25.40
1.875
47.63
.400
10.16
1.062
26.97
2.312
58.72
.500
12.70
1.125
28.58
2.375
60.33
.562
14.27
1.312
33.32
2.562
65.07
.670
17.02
1.375
34.93
2.625
66.68
.672
17.07
1.562
39.67
.688
17.48
1.625
41.28
1/ Metric equivalents are given for general information only.
Barometric pressure (reduced): Method 105 of MIL-STD-202, condition D (100,000 feet).
125 percent of dc rated voltage applied: See MIL-PRF-39022 for voltage limitations.
Vibration, high frequency: Method 204 of MIL-STD-202, condition D (20 g's peak).
50 percent of rated voltage applied.
Salt atmosphere (corrosion): Method 101 of MIL-STD-202, condition B (48 hours).
Salt solution: 5 percent.
Immersion: Method 104 of MIL-STD-202, condition C.
DWV:
Insulating sleeves: Greater than 4,000 volts, dc.
Terminal to terminal: 200 percent of rated voltage.
Terminals to case (when case is not a terminal): 200 percent of rated voltage.
IR:
Insulating sleeves: 100 megohms, minimum.
Terminal to terminal: Not less than 50 percent of value specified in table II.
Terminals to case (when case is not a terminal): 5,000 megohms, minimum.
Capacitance: Within ± 10 percent of initial value.
DF: Not more than 1.1 percent.
Solderability: Method 208 of MIL-STD-202.
