MIL-PRF-39018/6D
TABLE I. Style CUR91 capacitors - Continued.
Impedance
Maximum
DC rated
Capaci-
DC surge
ESR
(max)
DC leakage
ac ripple
Case
Dash number
@ -55°C
(max)
current 1/
2/
voltage
tance
voltage
(max)
size
@ 105°C
@ 105°C
25°C
105°C
120 Hz
(nom)
(120 Hz)
@ 85°C
µF
Volts
Volts
Ohms
Ohms
mA
Amps
15
20,000
20
.018
0.22
0.82
7.39
13.0
BB
0047-
15
30,000
20
.014
0.14
1.00
9.05
15.2
BC
0048-
15
35,000
20
.011
0.12
1.09
9.78
17.1
BD
0049-
15
40,000
20
.010
0.11
1.16
10.5
18.2
BE
0050-
15
42,000
20
.012
0.11
1.19
10.7
18.2
CB
0051-
15
45,000
20
.010
.096
1.23
11.1
19.5
BF
0052-
15
51,000
20
.010
.087
1.31
11.8
20.7
CC
0053-
15
59,000
20
.010
.075
1.41
12.7
21.8
CD
0054-
15
68,000
20
.009
.066
1.51
13.6
23.1
CE
0055-
15
76,000
20
.008
.060
1.60
14.4
24.5
CF
0056-
15
76,000
20
,010
.060
1.60
14.4
23.1
DC
0057-
15
89,000
20
.009
.054
1.73
15.6
25.7
DD
0058-
15
100,000
20
.009
.051
1.84
16.5
26.6
DE
0059-
15
110,000
20
.008
.048
1.93
17.3
27.5
DF
0060-
20
2,800
30
.044
1.47
0.35
3.19
6.1
AA
0061-
20
5,100
30
.026
0.81
0.48
4.31
8.5
AB
0062-
20
8,600
30
.020
0.48
0.62
5.60
9.9
AC
0063-
20
10,000
30
.019
0.41
0.67
6.04
11.0
AD
0064-
20
11,000
30
.017
0.37
0.70
6.33
11.7
AE
0065-
20
13,000
30
.016
0.32
0.76
6.88
12.0
AF
0066-
20
20,000
30
.013
0.21
0.95
8.54
15.4
BC
0067-
20
23,000
30
.013
0.18
1.02
9.16
15.8
BD
0068-
20
24,000
30
.016
0.17
1.04
9.35
16.0
CB
0069-
20
26,000
30
.012
0.16
1.08
9.73
16.5
BE
0070-
20
30,000
30
.012
0.14
1.16
10.5
17.2
BF
0071-
20
37,000
30
.012
0.11
1.29
11.6
18.8
CC
0072-
20
43,000
30
.011
0.10
1.39
12.5
19.9
CD
0073-
20
47,000
30
.010
.090
1.45
13.1
21.2
CE
0074-
20
54,000
30
.012
.081
1.56
14.0
22.0
DC
0075-
20
55,000
30
.009
.078
1.57
14.2
22.6
CF
0076-
20
63,000
30
.009
.069
1.68
15.2
24.5
DD
0077-
20
73,000
30
.009
.063
1.81
16.3
25.9
DE
0078-
20
82,000
30
.008
.057
1.92
17.3
26.5
DF
0079-
25
2,500
40
.050
1.64
0.38
3.38
5.7
AA
0080-
25
5,500
40
.031
0.75
0.56
5.00
7.7
AB
0081-
25
7,500
40
.021
0.55
0.65
5.85
9.6
AC
0082-
25
8,700
40
.020
0.47
0.70
6.30
10.0
AD
0083-
25
10,000
40
.019
0.41
0.75
6.75
11.0
AE
0084-
25
11,000
40
.018
0.37
0.79
7.08
12.0
AF
0085-
25
17,000
40
.015
0.25
0.98
8.80
14.5
BC
0086-
25
20,000
40
.012
0.21
1.06
9.54
16.1
BD
0087-
25
20,000
40
.011
0.21
1.06
9.54
16.8
CB
0088-
25
23,000
40
.011
0.18
1.14
10.2
16.8
BE
0089-
