MIL-PRF-39018/2F
Case
Dimensions
Inches
mm
Inches
mm
A ± .031
B ± .015
size
.002
0.05
.281
7.14
See note 5
.008
0.20
.375
9.52
.015
0.38
.938
23.83
A0
.938
.281
.031
0.79
1.438
36.53
A7
1.438
.375
.032
0.81
1.500
38.10
A8
2.125
.375
.140
3.56
2.125
53.97
A9
2.750
.375
.250
6.35
2.750
69.85
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. These capacitors are not intended to be mounted by their leads.
4. There is an indeterminate resistance between terminal and case. Optional configuration may allow that one
lead be connected to the case (single ended construction).
5. The "B" dimension for style CU15 shall not be more than .008 (0.20 mm) larger than the specified bare case
diameter.
FIGURE 1. Styles CU14 and CU15 capacitors - Continued.
