INCH-POUND
MIL-PRF-23269/10D
31 July 2009
SUPERSEDING
MIL-PRF-23269/10C
10 June 1999
PERFORMANCE SPECIFICATION SHEET
CAPACITORS, FIXED, GLASS DIELECTRIC,
(RADIAL OR AXIAL WIRE-LEAD TERMINALS), ESTABLISHED RELIABILITY,
STYLES CYR51, CYR52, AND CYR53
This specification sheet is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and MIL-PRF-23269.
Inches
mm
Inches
mm
.002
0.05
.115
2.92
.005
0.13
.200
5.08
.010
0.25
.300
7.62
.020
0.51
1.25
31.8
.050
1.27
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. See marking requirement.
FIGURE 1. Dimensions and configuration for style CLR51.
AMSC N/A
FSC 5910
