MIL-PRF-20/38C
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Lead type: Radial.
Case type: Molded.
DC rated voltage: See table I.
Operating temperature range: -55°C to +125°C.
Characteristic: CG.
Failure rate level (CCR08 only): M (1.0 percent), P (0.1 percent), R (.01 percent) or S (.001 percent).
Thermal shock and voltage conditioning (CCR08 only): In accordance with MIL-PRF-20.
Capacitance: Within tolerance specified (see table I).
Dissipation factor: In accordance with MIL-PRF-20.
Dielectric withstanding voltage: In accordance with MIL-PRF-20.
Body insulation: Test II.
TABLE I. Capacitor characteristics.
PIN
PIN
Capacitance
Capacitance
Rated
Rated
Nominal
Nominal
1/
1/
tolerance
tolerance
voltage capacitance
voltage capacitance
(pF)
(pF)
(volts, dc)
(volts, dc)
GJK
18,000
100
CC-08CG183--
GJK
3,900
200
CC-08CG392--
GJK
56,000
50
CC-08CG563--
GJK
4,700
200
CC-08CG472--
GJK
68,000
50
CC-08CG683--
GJK
15,000
100
CC-08CG153--
1/ Complete PIN will include the following:
1st dash - Symbol "R" (for style CCR08) or dash will be deleted (for style CC08).
2nd dash - Applicable capacitance tolerance symbol.
3rd dash - Applicable failure rate level symbol (CCR08 only) or dash will be deleted (for style CC08).
Solderability: In accordance with MIL-PRF-20.
Resistance to soldering heat: In accordance with MIL-PRF-20.
Life: In accordance with MIL-PRF-20, operating condition 2.
Part or Identifying Number (PIN): In accordance with MIL-PRF-20 and table I.
Marking: In accordance with MIL-PRF-20.
Changes from previous issue: The margins of this specification sheet are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the Government
assumes no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal notations and
relationship to the last previous issue.
