MIL-PRF-20/31C
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Lead type: Axial.
Case type: Tubular, molded.
DC rated voltage: See table I.
Operating temperature range: -55°C to +125°C.
Characteristic: CG.
TABLE I. Capacitor characteristics.
PIN
PIN
Capacitance
Capacitance
Nominal
Nominal
Rated
Rated
1/
1/
tolerance
tolerance
voltage capacitance
voltage capacitance
(pF)
(pF)
(volts, dc)
(volts, dc)
CC-79CG392--
200
3,900
FGJK
CC-79CG223--
100
22,000
FGJK
CC-79CG472--
200
4,700
FGJK
CC-79CG273--
100
27,000
FGJK
CC-79CG562--
200
5,600
FGJK
CC-79CG333--
100
33,000
FGJK
CC-79CG682--
200
6,800
FGJK
CC-79CG393--
100
39,000
FGJK
CC-79CG822--
200
8,200
FGJK
CC-79CG473--
50
47,000
FGJK
CC-79CG103--
200
10,000
FGJK
CC-79CG563--
50
56,000
FGJK
CC-79CG153--
100
15,000
FGJK
CC-79CG683--
50
68,000
FGJK
CC-79CG183--
100
18,000
FGJK
CC-79CG823--
50
82,000
FGJK
1/ Complete PIN will include the following:
1st dash - Symbol "R" (for style CCR79) or dash will be deleted (for style CC79).
2nd dash - Applicable capacitance tolerance symbol.
3rd dash - Applicable failure rate level symbol (CCR79 only) or dash will be deleted (for style CC79).
Failure rate level (CCR79 only): M (1.0 percent), P (0.1 percent), R (0.01 percent) or S (0.001 percent).
Thermal shock and voltage conditioning (CCR79 only): In accordance with MIL-PRF-20.
Capacitance: Within tolerance specified (see table I).
Dissipation factor: In accordance with MIL-PRF-20.
Dielectric withstanding voltage: In accordance with MIL-PRF-20.
Body insulation: Test II.
Solderability: In accordance with MIL-PRF-20.
Resistance to soldering heat: In accordance with MIL-PRF-20.
Life: In accordance with MIL-PRF-20, operating condition 2.
Part or Identifying Number (PIN): In accordance with MIL-PRF-20 and table I.
Marking: In accordance with MIL-PRF-20.
