MIL-PRF-19978/14A
TABLE II. STYLES CQR32 capacitors - Continued.
DC
Case dimensions
voltage Capacitance Capacitance
Failure
Circuit 1
Circuit 3
Part number 1/
rating
rating
tolerance
rate
L .031 D +.015, L .031 D +.015,
level
-.005
-.005
Volts
Inches
Inches
Inches
Inches
F
CQR32A-MC474-3-
200
.47
G, J, K
M, P, R, S
1.188
.500
1.094
.500
CQR32A-MC564-3-
200
.56
G, J, K
M, P, R, S
1.375
.562
1.281
.562
CQR32A-MC684-3-
200
.68
G, J, K
M, P, R, S
1.375
.562
1.281
.562
CQR32A-MC824-3-
200
.82
G, J, K
M, P, R, S
1.875
.562
1.781
.562
CQR32A-MC105-3-
200
1.0
G, J, K
M, P, R, S
1.875
.562
1.781
.562
CQR32A-ME102-3-
400
.0010
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-ME122-3-
400
.0012
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-ME152-3-
400
.0015
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-ME182-3-
400
.0018
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-ME222-3-
400
.0022
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-ME272-3-
400
.0027
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-ME332-3-
400
.0033
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-ME392-3-
400
.0039
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-ME472-3-
400
.0047
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-ME562-3-
400
.0056
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR32A-ME682-3-
400
.0068
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR32A-ME822-3-
400
.0082
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR32A-ME103-3-
400
.010
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR32A-ME123-3-
400
.012
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR32A-ME153-3-
400
.015
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR32A-ME183-3-
400
.018
G, J, K
M, P, R, S
1.062
.312
.969
.312
CQR32A-ME223-3-
400
.022
G, J, K
M, P, R, S
1.062
.312
.969
.312
CQR32A-ME273-3-
400
.027
G, J, K
M, P, R, S
.938
.400
.844
.400
CQR32A-ME333-3-
400
.033
G, J, K
M, P, R, S
.938
.400
.844
.400
CQR32A-ME393-3-
400
.039
G, J, K
M, P, R, S
1.062
.400
.969
.400
CQR32A-ME473-3-
400
.047
G, J, K
M, P, R, S
1.062
.400
.969
.400
CQR32A-ME563-3-
400
.056
G, J, K
M, P, R, S
1.250
.400
1.156
.400
CQR32A-ME683-3-
400
.068
G, J, K
M, P, R, S
1.250
.400
1.156
.400
CQR32A-ME823-3-
400
.082
G, J, K
M, P, R, S
1.562
.400
1.469
.400
CQR32A-ME104-3-
400
.10
G, J, K
M, P, R, S
1.562
.400
1.469
.400
CQR32A-ME124-3-
400
.12
G, J, K
M, P, R, S
1.281
.562
1.188
.562
CQR32A-ME154-3-
400
.15
G, J, K
M, P, R, S
1.281
.562
1.188
.562
CQR32A-ME184-3-
400
.18
G, J, K
M, P, R, S
1.531
.562
1.438
.562
CQR32A-ME224-3-
400
.22
G, J, K
M, P, R, S
1.531
.562
1.438
.562
CQR32A-ME274-3-
400
.27
G, J, K
M, P, R, S
1.906
.562
1.812
.562
CQR32A-ME334-3-
400
.33
G, J, K
M, P, R, S
1.906
.562
1.812
.562
CQR32A-ME394-3-
400
.39
G, J, K
M, P, R, S
1.906
.670
1.812
.670
CQR32A-ME474-3-
400
.47
G, J, K
M, P, R, S
1.906
.670
1.812
.670
CQR32A-ME564-3-
400
.56
G, J, K
M, P, R, S
2.156
.750
2.062
.750
CQR32A-ME684-3-
400
.68
G, J, K
M, P, R, S
2.156
.750
2.062
.750
CQR32A-ME824-3-
400
.82
G, J, K
M, P, R, S
2.656
.750
2.562
.750
CQR32A-ME105-3-
400
1.0
G, J, K
M, P, R, S
2.656
.750
2.562
.750
CQR32A-MF102-3-
600
.0010
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-MF122-3-
600
.0012
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-MF152-3-
600
.0015
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-MF182-3-
600
.0018
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-MF222-3-
600
.0022
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-MF272-3-
600
.0027
G, J, K
M, P, R, S
.812
.235
.719
.235
CQR32A-MF332-3-
600
.0033
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR32A-MF392-3-
600
.0039
G, J, K
M, P, R, S
.938
.312
.844
.312
