INCH-POUND
MIL-PRF-19978/14A
27 May 1999
SUPERSEDING
MIL-C-19978/14
20 October 1972
PERFORMANCE SPECIFICATION SHEET
CAPACITORS, FIXED, PLASTIC DIELECTRIC, AXIAL-WIRE TERMINAL,
TANGENTIAL RETAINER, TUBULAR (UNINSULATED)
(HERMETICALLY SEALED IN METAL CASES),
ESTABLISHED RELIABILITY, STYLE CQR32
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The complete requirements for procuring the capacitors described herein
shall consist of this specification and MIL-PRF-19978.
SEE
GROUNDED END
NOTE 3
E
H
F
.0625 MAX
G
Inches
mm
Inches
mm
Inches
mm
.001
.03
.0625
1.59
.250
6.35
.004
.10
.144
3.66
.312
7.92
.005
.13
.156
3.96
.400
10.16
.020
.51
.172
4.37
.438
11.13
.025
.64
.175
4.45
.500
12.70
.031
.79
.188
4.78
.562
14.27
.032
.81
.195
4.95
1.000
25.40
.062
1.57
.235
5.97
1.625
41.28
Case dimension D
H .062
G .062
E .031
F .005
Less than .500
.312
.250
.188
.144
.500 and up
.438
.500
.250
.156
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Leads shall be of tinned solid wire, .020 (No. 24 AWG) for cases .175 and .195 in diameter; .025 (No. 22 AWG)
for cases .235 through .312 diameter; and .032 (No. 20 AWG) for cases .400 diameter and above. Tolerance
on all lead wire diameters shall be + .004, -.001.
FIGURE 1. Style CQR32 capacitors.
AMSC N/A
1 of 8
FSC 5910
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
