MIL-PRF-19978/11C
TABLE II. STYLE CQR13 capacitors - Continued.
Case dimensions 2/
Failure
DC
Capacitance Capacitance
Part or Identifying
Circuit 1
Circuit 3
rate
voltage
rating
tolerance
Number (PIN) 1/
D +.015,
D +.015,
L .031
L .031
levels
rating
-.005
-.005
F
Volts
Inches
Inches
Inches
Inches
CQR13A-KF222-3-
600
.0022
G, J, K
M, P, R, S
.750
.400
.688
.400
CQR13A-KF272-3-
600
.0027
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KF332-3-
600
.0033
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KF392-3-
600
.0039
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KF472-3-
600
.0047
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KF562-3-
600
.0056
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KF682-3-
600
.0068
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KF822-3-
600
.0082
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KF103-3-
600
.010
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KF123-3-
600
.012
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KF153-3-
600
.015
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KF183-3-
600
.018
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KF223-3-
600
.022
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KF273-3-
600
.027
G, J, K
M, P, R, S
1.125
.400
1.062
.400
CQR13A-KF333-3-
600
.033
G, J, K
M, P, R, S
1.125
.400
1.062
.400
CQR13A-KF393-3-
600
.039
G, J, K
M, P, R, S
1.375
.400
1.312
.400
CQR13A-KF473-3-
600
.047
G, J, K
M, P, R, S
1.375
.400
1.312
.400
CQR13A-KF563-3-
600
.056
G, J, K
M, P, R, S
1.125
.562
1.062
.562
CQR13A-KF683-3-
600
.068
G, J, K
M, P, R, S
1.125
.562
1.062
.562
CQR13A-KF823-3-
600
.082
G, J, K
M, P, R, S
1.375
.562
1.312
.562
CQR13A-KF104-3-
600
.10
G, J, K
M, P, R, S
1.375
.562
1.312
.562
CQR13A-KF124-3-
600
.12
G, J, K
M, P, R, S
1.625
.562
1.562
.562
CQR13A-KF154-3-
600
.15
G, J, K
M, P, R, S
1.625
.562
1.562
.562
CQR13A-KF184-3-
600
.18
G, J, K
M, P, R, S
1.625
.670
1.562
.670
CQR13A-KF224-3-
600
.22
G, J, K
M, P, R, S
1.625
.670
1.562
.670
CQR13A-KF274-3-
600
.27
G, J, K
M, P, R, S
2.125
.750
2.062
.750
CQR13A-KF334-3-
600
.33
G, J, K
M, P, R, S
2.125
.750
2.062
.750
CQR13A-KF394-3-
600
.39
G, J, K
M, P, R, S
2.375
.750
2.312
.750
CQR13A-KF474-3-
600
.47
G, J, K
M, P, R, S
2.375
.750
2.312
.750
CQR13A-KG184-3-
1,000
.18
G, J, K
M, P, R, S
2.125
.750
2.062
.750
CQR13A-KG224-3-
1,000
.22
G, J, K
M, P, R, S
2.125
.750
2.062
.750
CQR13A-KG274-3-
1,000
.27
G, J, K
M, P, R, S
2.125
1.0
2.062
1.000
CQR13A-KG334-3-
1,000
.33
G, J, K
M, P, R, S
2.125
1.0
2.062
1.000
CQR13A-KG394-3-
1,000
.39
G, J, K
M, P, R, S
2.375
1.0
2.312
1.000
CQR13A-KG474-3-
1,000
.47
G, J, K
M, P, R, S
2.375
1.0
2.312
1.000
1/ Complete part number shall include additional symbols to indicate circuit, capacitance tolerance, and failure rate
level, as applicable.
2/ See table III for metric equivalents.
