MIL-PRF-19978/11C
TABLE II. STYLE CQR13 capacitors.
Case dimensions 2/
Failure
DC
Capacitance Capacitance
Part or Identifying
Circuit 1
Circuit 3
rate
voltage
rating
tolerance
Number (PIN) 1/
D +.015,
D +.015,
L .031
L .031
levels
rating
-.005
-.005
F
Volts
Inches
Inches
Inches
Inches
CQR13A-KC392-3-
200
.0039
G, J, K
M, P, R, S
.750
.400
.688
.400
CQR13A-KC472-3-
200
.0047
G, J, K
M, P, R, S
.750
.400
.688
.400
CQR13A-KC562-3-
200
.0056
G, J, K
M, P, R, S
.750
.400
.688
.400
CQR13A-KC682-3-
200
.0068
G, J, K
M, P, R, S
.750
.400
.688
.400
CQR13A-KC183-3-
200
.018
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KC223-3-
200
.022
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KC273-3-
200
.027
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KC333-3-
200
.033
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KC393-3-
200
.039
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KC473-3-
200
.047
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KC563-3-
200
.056
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KC683-3-
200
.068
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KC823-3-
200
.082
G, J, K
M, P, R, S
1.125
.400
1.062
.400
CQR13A-KC104-3-
200
.10
G, J, K
M, P, R, S
1.125
.400
1.062
.400
CQR13A-KC124-3-
200
.12
G, J, K
M, P, R, S
1.375
.400
1.312
.400
CQR13A-KC154-3-
200
.15
G, J, K
M, P, R, S
1.375
.400
1.312
.400
CQR13A-KC184-3-
200
.18
G, J, K
M, P, R, S
1.125
.562
1.062
.562
CQR13A-KC224-3-
200
.22
G, J, K
M, P, R, S
1.125
.562
1.062
.562
CQR13A-KC274-3-
200
.27
G, J, K
M, P, R, S
1.375
.562
1.312
.562
CQR13A-KC334-3-
200
.33
G, J, K
M, P, R, S
1.375
.562
1.312
.562
CQR13A-KC394-3-
200
.39
G, J, K
M, P, R, S
1.625
.562
1.562
.562
CQR13A-KC474-3-
200
.47
G, J, K
M, P, R, S
1.625
.562
1.562
.562
CQR13A-KC564-3-
200
.56
G, J, K
M, P, R, S
1.625
.670
1.562
.670
CQR13A-KC684-3-
200
.68
G, J, K
M, P, R, S
1.625
.670
1.562
.670
CQR13A-KC824-3-
200
.82
G, J, K
M, P, R, S
2.125
.750
2.062
.750
CQR13A-KC105-3-
200
1.000
G, J, K
M, P, R, S
2.125
.750
2.062
.750
CQR13A-KE272-3-
400
.0027
G, J, K
M, P, R, S
.750
.400
.688
.400
CQR13A-KE332-3-
400
.0033
G, J, K
M, P, R, S
.750
.400
.688
.400
CQR13A-KE123-3-
400
.012
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KE153-3-
400
.015
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KE273-3-
400
.027
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KE333-3-
400
.033
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR13A-KE393-3-
400
.039
G, J, K
M, P, R, S
1.125
.400
1.062
.400
CQR13A-KE473-3-
400
.047
G, J, K
M, P, R, S
1.125
.400
1.062
.400
CQR13A-KE563-3-
400
.056
G, J, K
M, P, R, S
1.375
.400
1.312
.400
CQR13A-KE683-3-
400
.068
G, J, K
M, P, R, S
1.375
.400
1.312
.400
CQR13A-KE823-3-
400
.082
G, J, K
M, P, R, S
1.125
.562
1.062
.562
CQR13A-KE104-3-
400
.10
G, J, K
M, P, R, S
1.125
.562
1.062
.562
CQR13A-KE124-3-
400
.12
G, J, K
M, P, R, S
1.375
.562
1.312
.562
CQR13A-KE154-3-
400
.15
G, J, K
M, P, R, S
1.375
.562
1.312
.562
CQR13A-KE184-3-
400
.18
G, J, K
M, P, R, S
1.625
.562
1.562
.562
CQR13A-KE224-3-
400
.22
G, J, K
M, P, R, S
1.625
.562
1.562
.562
CQR13A-KE274-3-
400
.27
G, J, K
M, P, R, S
1.625
.670
1.562
.670
CQR13A-KE334-3-
400
.33
G, J, K
M, P, R, S
1.625
.670
1.562
.670
CQR13A-KE394-3-
400
.39
G, J, K
M, P, R, S
2.125
.750
2.062
.750
CQR13A-KE474-3-
400
.47
G, J, K
M, P, R, S
2.125
.750
2.062
.750
CQR13A-KF102-3-
600
.0010
G, J, K
M, P, R, S
.750
.400
.688
.400
CQR13A-KF122-3-
600
.0012
G, J, K
M, P, R, S
.750
.400
.688
.400
CQR13A-KF152-3-
600
.0015
G, J, K
M, P, R, S
.750
.400
.688
.400
CQR13A-KF182-3-
600
.0018
G, J, K
M, P, R, S
.750
.400
.688
.400
